Midea MGC-F16W/SN1

Specification MCAC-TSM-2008-02
22 Installation
MGC-F07W/N1
Ta
Tw 5.0 6.0 7.0 8.0 9.0 10.0
Pf 7.3 7.4 7.6 7.7 7.8 8.0
Pa 2.3 2.3 2.3 2.3 2.4 2.4
Pat 2.6 2.6 2.6 2.6 2.7 2.7
Qev 1.26 1.27 1.31 1.32 1.34 1.38
25.0
ΔPev 35.6 37.0 38.6 40.3 41.8 43.5
Pf 7.1 7.2 7.3 7.5 7.6 7.7
Pa 2.6 2.6 2.6 2.6 2.7 2.7
Pat 2.9 2.9 2.9 2.9 3.0 3.0
Qev 1.22 1.24 1.26 1.29 1.31 1.32
30.0
ΔPev 32.4 33.7 36.1 37.6 39.1 40.6
Pf 7.0 7.1 7.2 7.3 7.4 7.5
Pa 2.6 2.6 2.6 2.7 2.7 2.7
Pat 2.9 2.9 2.9 3.0 3.0 3.0
Qev 1.20 1.22 1.24 1.26 1.27 1.29
35.0
ΔPev 32.5 33.8 35.0 36.5 38.0 39.5
Pf 6.8 6.9 7.1 7.2 7.3 7.4
Pa 2.7 2.7 2.7 2.8 2.8 2.8
Pat 3.0 3.0 3.0 3.1 3.1 3.1
Qev 1.17 1.19 1.22 1.24 1.26 1.27
40.0
ΔPev 31.1 32.3 33.6 34.9 36.3 37.7
Pf 6.5 6.7 6.8 6.9 7.1 7.2
Pa 2.9 2.9 2.9 3.0 3.0 3.0
Pat 3.2 3.2 3.2 3.3 3.3 3.3
Qev 1.12 1.15 1.17 1.19 1.22 1.24
43.0
ΔPev 28.8 29.9 31.1 32.3 33.5 34.8
Note:
Ta: outside air temperature (°C)
Tw : evaporator water outlet temperature (°C)
Pf: cooling capacity (kW)
Pa: compressor power input (kW)
Pat: total power input (kW)
Qev: evaporator water flow (m
3
/h)
ΔPev: evaporator pressure drop (kPa)
