Midea MGC-F16W/SN1

MCAC-TSM-2008-02 Outdoor units
Outdoor units 23
MGC-F09W/N1
Ta Tw 5 6 7 8 9 10
Pf 8.3 8.6 8.9 9.2 9.5 9.8
Pa 2.6 2.6 2.6 2.7 2.7 2.7
Pat 2.9 2.9 2.9 3.0 3.0 3.0
Qev 1.4 1.5 1.5 1.6 1.6 1.7
25
Pev△ 36 41 43 46.4 48 51
Pf 7.9 8.2 8.5 8.8 9.1 9.4
Pa 2.8 2.8 2.8 2.9 2.9 2.9
Pat 3.1 3.1 3.1 3.2 3.2 3.2
Qev 1.3 1.4 1.4 1.5 1.5 1.6
30
Pev△ 29.5 32.1 35.6 39.0 41.8 47.0
Pf 7.5 7.8 8.0 8.2 8.5 8.8
Pa 3.1 3.1 3.2 3.3 3.3 3.3
Pat 3.4 3.4 3.5 3.6 3.6 3.6
Qev 1.3 1.3 1.4 1.4 1.5 1.5
35
Pev△ 28.0 30.4 33.9 35.0 38.0 420
Pf 7.0 7.3 7.5 7.7 8.0 8.3
Pa 3.4 3.4 3.5 3.6 3.6 3.6
Pat 3.7 3.7 3.8 3.9 3.9 3.9
Qev 1.2 1.3 1.3 1.4 1.4 1.4
40
Pev△ 24.0 26.0 26.8 28.0 32.1 35.3
Pf 6.8 7.1 7.3 7.5 7.8 8.1
Pa 3.6 3.6 3.7 3.8 3.8 3.8
Pat 3.9 3.9 4.0 4.1 4.1 4.1
Qev 1.1 1.2 1.2 1.3 1.3 1.4
43
Pev△ 20.0 23.5 24.6 28.0 31.0 34.0
Note:
Ta: outside air temperature (°C)
Tw : evaporator water outlet temperature (°C)
Pf: cooling capacity (kW)
Pa: compressor power input (kW)
Pat: total power input (kW)
Qev: evaporator water flow (m
3
/h)
ΔPev: evaporator pressure drop (kPa)
