Specification MCAC-TSM-2008-02
24 Installation
MGC-F10W/N1
Ta Tw 5 6 7 8 9 10
Pf 10.9 11.2 11.5 11.8 12.1 12.4
Pa 2.6 2.6 2.7 2.7 2.7 2.8
Pat 3.1 3.1 3.2 3.2 3.2 3.3
Qev 1.9 1.9 2.0 2.0 2.1 2.2
25
Pev△ 31.5 31.7 33.0 33.5 36.0 38.0
Pf 10.4 10.8 11.1 11.5 11.8 12.1
Pa 2.9 2.9 3.0 3.1 3.1 3.1
Pat 3.4 3.4 3.5 3.6 3.6 3.6
Qev 1.8 1.8 1.9 2.0 2.0 2.0
30
Pev△ 29.8 30.4 31.8 33.2 33.6 33.9
Pf 9.9 10.2 10.5 10.7 11.0 11.3
Pa 3.3 3.3 3.4 3.4 3.5 3.5
Pat 3.8 3.8 3.9 3.9 4.0 4.0
Qev 1.7 1.7 1.8 1.9 1.9 2.0
35
Pev△ 27.0 27.5 30.0 32.0 32.4 34.0
Pf 9.4 9.7 10.0 10.3 10.6 11.0
Pa 3.6 3.6 3.7 3.7 3.8 3.8
Pat 4.1 4.1 4.2 4.2 4.3 4.3
Qev 1.6 1.6 1.7 1.7 1.8 1.8
40
Pev△ 24.0 24.4 27.2 27.6 30.3 30.5
Pf 9.0 9.3 9.5 9.8 10.0 10.3
Pa 3.8 3.8 3.9 3.9 4.0 4.0
Pat 4.3 4.3 4.4 4.4 4.5 4.5
Qev 1.5 1.6 1.6 1.7 1.7 1.8
43
Pev△ 21.0 23.8 24.4 27.0 27.5 31.0
Note:
Ta: outside air temperature (°C)
Tw : evaporator water outlet temperature (°C)
Pf: cooling capacity (kW)
Pa: compressor power input (kW)
Pat: total power input (kW)
Qev: evaporator water flow (m
3
/h)
ΔPev: evaporator pressure drop (kPa)
