Specification MCAC-TSM-2008-02
26 Installation
MGC-F12W/SN1
Ta Tw 5 6 7 8 9 10
Pf 12.4 12.7 13.0 13.3 13.9
Pa 3.5 3.5 3.5 3.6 3.6 3.6
Pat 4.1 4.1 4.1 4.2 4.2 4.2
Qev 2.2 2.2 2.3 2.3 2.3 2.4
25
Pev△ 29.1 29.9 31.0 32.4 34.1 37.5
Pf 11.9 12.2 12.5 12.8 13.1 13.4
Pa 3.8 3.8 3.8 3.9 3.9 3.9
Pat 4.4 4.4 4.4 4.5 4.5 4.5
Qev 2.0 2.1 2.1 2.2 2.2 2.3
30
Pev△ 23.1 23.2 25.4 27.0 28.8 30.0
Pf 11.4 11.7 12.0 12.3 12.6 12.9
Pa 4.2 4.2 4.2 4.3 4.3 4.3
Pat 4.8 4.8 4.8 4.9 4.9 4.9
Qev 2.0 2.0 2.1 2.1 2.2 2.2
35
Pev△ 21.1 23.2 25.4 27.0 28.8 30.0
Pf 10.9 11.2 11.5 11.8 12.1 12.4
Pa 4.5 4.5 4.5 4.6 4.6 4.6
Pat 5.1 5.1 5.1 5.2 5.2 5.2
Qev 1.9 2.0 2.0 2.0 2.1 2.1
40
Pev△ 20.2 21.9 22.7 24.0 25.6 28.2
Pf 10.5 10.8 11.1 11.4 11.7 12.0
Pa 4.7 4.7 4.7 4.8 4.8 4.8
Pat 5.3 5.3 5.3 5.4 5.4 5.4
Qev 1.8 1.9 1.9 2.0 2.0 2.0
43
Pev△ 17.5 18.8 21.1 23.4 24.1 25.3
Note:
Ta: outside air temperature (°C)
Tw : evaporator water outlet temperature (°C)
Pf: cooling capacity (kW)
Pa: compressor power input (kW)
Pat: total power input (kW)
Qev: evaporator water flow (m 3 /h)
ΔPev: evaporator pressure drop (kPa)
