MCAC-TSM-2008-02 Outdoor units
Outdoor units 27
MGC-F14W/SN1
Ta Tw 5 6 7 8 9 10
Pf 14.8 15.1 15.4 15.7 16.1 16.4
Pa 3.6 3.6 3.6 3.7 3.7 3.7
Pat 4.1 4.1 4.1 4.2 4.2 4.2
Qev 2.6 2.6 2.7 2.7 2.8 2.8
25
Pev△ 29.0 29.4 30.4 31.2 33.0 34.0
Pf 14.1 14.4 14.7 15.0 15.3 15.6
Pa 4.1 4.1 4.1 4.2 4.2 4.2
Pat 4.6 4.6 4.7 4.7 4.7 4.7
Qev 2.4 2.5 2.5 2.6 2.6 2.7
30
Pev△ 25.8 28.2 28.4 28.9 29.5 31.0
Pf 13.4 13.7 14.0 14.3 14.6 14.9
Pa 4.6 4.6 4.6 4.7 4.7 4.7
Pat 5.1 5.1 5.1 5.2 5.2 5.2
Qev 2.3 2.4 2.4 2.5 2.5 2.5
35
Pev△ 24.0 25.6 26.0 27.6 28.1 28.4
Pf 12.5 12.8 13.1 13.4 13.7 14.0
Pa 5.1 5.1 5.1 5.2 5.2 5.2
Pat 5.6 5.6 5.6 5.7 5.7 5.7
Qev 2.2 2.2 2.3 2.3 2.4 2.4
40
Pev△ 19.6 20.3 21.6 23.4 25.7 26.4
Pf 12.0 12.3 12.6 12.9 13.2 13.5
Pa 5.5 5.5 5.5 5.6 5.6 5.6
Pat 6.0 6.0 6.0 6.1 6.1 6.1
Qev 2.1 2.1 2.2 2.2 2.3 2.3
43
Pev△ 18.0 19.1 20.7 21.3 23.0 23.8
Note:
Ta: outside air temperature (°C)
Tw : evaporator water outlet temperature (°C)
Pf: cooling capacity (kW)
Pa: compressor power input (kW)
Pat: total power input (kW)
Qev: evaporator water flow (m 3 /h)
ΔPev: evaporator pressure drop (kPa)
