MCAC-TSM-2008-02 Outdoor units
Outdoor units 29
Heating
MGC-F05W/N1
Ta
U.R.87%
Tw 35 40 45 50
Pt 4.2 4.2 4.1 -
Pa 1.3 1.5 1.6 -
Pat 1.5 1.7 1.8 -
Qc 0.72 0.72 0.71 -
-5
ΔPc 14.6 14.5 14.1 -
Pt 4.8 4.8 4.7 4.7
Pa 1.3 1.5 1.7 1.9
Pat 1.6 1.8 2 2.2
Qc 0.83 0.83 0.81 0.81
0
ΔPc 18.5 18.4 18.1 18.1
Pt 5.6 5.5 5.5 5.4
Pa 1.4 1.5 1.7 1.9
Pat 1.7 1.8 2 2.2
Qc 0.96 0.95 0.95 0.93
7
ΔPc 23.9 23.4 23 22.9
Pt 6.1 6.1 6 6
Pa 1.4 1.5 1.7 1.9
Pat 1.7 1.8 2 2.2
Qc 1.05 1.05 1.03 1.03
10
ΔPc 27.8 27.5 27.1 27
Pt 6.5 6.5 6.5 6.4
Pa 1.4 1.6 1.7 1.9
Pat 1.7 1.9 2 2.2
Qc 1.12 1.12 1.12 1.10
15
ΔPc 33.2 33 32.9 32.5
Note:
Ta: outside air temperature (°C)
Tw : evaporator water outlet temperature (°C)
Pt: heating capacity (kW)
Pa: compressor power input (kW)
Pat: total power input (kW)
Qc: condenser water flow (m3/h)
ΔPc: evaporator pressure drop (kPa)
- : Exceed operating limits
