Specification MCAC-TSM-2008-02
30 Installation
MGC-F07W/N1
Ta
U.R.87%
Tw 35 40 45 50
Pt 6.4 6.4 6.3 /
Pa 2.2 2.4 2.5 /
Pat 2.5 2.7 2.8 /
Qc 1.10 1.10 1.08 /
-5
ΔPc 27.6 27.5 27.1 /
Pt 7 7 6.9 6.9
Pa 2.2 2.4 2.6 2.8
Pat 2.5 2.7 2.9 3.1
Qc 1.20 1.20 1.19 1.19
0
ΔPc 31.5 31.4 31.1 31.1
Pt 7.8 7.7 7.7 7.6
Pa 2.3 2.4 2.6 2.8
Pat 2.6 2.7 2.9 3.1
Qc 1.34 1.32 1.32 1.31
7
ΔPc 36.9 36.4 36 35.9
Pt 8.3 8.3 8.2 8.2
Pa 2.3 2.4 2.6 2.8
Pat 2.6 2.7 2.9 3.1
Qc 1.43 1.43 1.41 1.41
10
ΔPc 40.8 40.5 40.1 40
Pt 8.7 8.7 8.7 8.6
Pa 2.3 2.5 2.6 2.8
Pat 2.6 2.8 2.9 3.1
Qc 1.50 1.50 1.50 1.48
15
ΔPc 46.2 46 45.9 45.5
Note:
Ta: outside air temperature (°C)
Tw : evaporator water outlet temperature (°C)
Pt: heating capacity (kW)
Pa: compressor power input (kW)
Pat: total power input (kW)
Qc: condenser water flow (m3/h)
ΔPc: evaporator pressure drop (kPa)
- : Exceed operating limits
