Specifications MCAC-UTSM-2008-05
10 Ceiling and Floor Type
Table 2:
Model name
MUB-12HRDN1
Indoor Units
Power supply 220-240V-1Ph-50Hz
Model name
MOU-12HRDN1
Model
Outdoor Units
Power supply 220~240V-1P-50Hz
Capacity kW 4.0-3.5-1.4
Input kW 2.55-1.08-0.38
Rated current A 12-5.1-2.0
Cooling
EER 3.24
Capacity kW 4.75-4.0-1.4
Input kW 2.55-1.12-0.38
Rated current A 12-5.2-2.0
Heating
COP 3.6
Max. input consumption W 2550
Max. current A 12
Model DA108X1C-20FZ3
Type DC Inverter Rotary
Brand MIDEA TOSHIBA
Capacity Btu/h 10921
Input W 855
Rated current(RLA) A 5.3
Locked rotor Amp(LRA) A 20
Thermal protector Internal
Compressor
Refrigerant oil ml ESTER OIL VG74 480ml
Model YSK25-6L
Type AC Motor
Brand Welling
Input W 33.4/31.1/29.5
Capacitor uF 1.2
Indoor fan motor
Speed(hi/mi/lo) r/min 756/666/592
a. Number of rows 3
b. Tube pitch(a)x row pitch(b) mm 25.4×22
c. Fin spacing mm 1.8
d. Fin type (code) Hydrophilic aluminium
Ф9.53
e. Tube outside dia. and type mm
innergroove tube
f. Coil length x height x width mm 804x254x66
Indoor coil
g. Number of circuits 3
Indoor air flow (Hi/Mi/Lo) m
3
/h 584/518/463
Indoor noise level (Sound pressure)(Hi/Mi/Lo) dB(A) 39.6/36.7/33.1
Dimension (W×H×D) mm 990x206x660
Indoor unit
Packing (W×H×D) mm 1089x296 x744
