Midea MOUA-60HN1-R User Manual

MCAC-UTSM-2008-11 Specifications
Outdoor Units 89
1. Specifications
Model MOU-12HN1 MOUA-18HN1
Code 220075100110 220075200490
Power supply V-ph-Hz
220~240-1-50 220~240-1-50
Max. input consumption W 1500 2400
Max. input current A 7.0 10.9
Starting current A 26 53
Compressor
Model PA140X2C-4FT PA225X2CS-4KU1
Type ROTARY ROTARY
Brand MIDEA-TOSHIBA MIDEA-TOSHIBA
Supplier MIDEA-TOSHIBA MIDEA-TOSHIBA
Capacity Btu/h 11567 18697
Input W 1150 1855
Rated current(RLA) A 5.3 8.7
Locked rotor Amp(LRA)
A 29.9 36.8
Thermal protector Internal Internal
Capacitor μF 35μF/440-450V 50μF/440V-450V
Refrigerant oil ml ESTEL OIL VG74, 480 ESTER OIL VG74, 750
Outdoor fan
motor
Model YDK24-6F YDK48-6H(A)
Type AC motor AC motor
Brand Welling Welling
Input W 58 110
Capacitor μF 2.5uF/450V 3μF/450V
Speed r/min 800 890
Outdoor coil
Number of rows 2 2
Tube pitch(a)× row
pitch(b)
mm 21×13.37 22×19.05
Fin spacing mm 1.5 1.4
Fin type Hydrophilic aluminium Hydrophilic aluminium
Tube outside dia.and type
mm
φ
7 Inner grooved copper
tube
φ
7.94 Inner grooved copper
tube
Coil length × height ×
width
mm 651×559×26.74 645×528×38.1
Number of circuits 2 5
Outdoor air flow m
3
/h 2100 2439
Outdoor noise level (sound pressure) dB(A) 43 48
Outdoor unit
Dimension(W×H×D) mm 838(780)×547×250 824(762)×593×282
Packing (W×H×D) mm 910×575×335 891×657×359
Net/Gross weight kg 37/39 41/44
Refrigerant
Type R410A R410A
Charged volume g 1120 1450
Design pressure MPa 4.4/2.6 4.4/2.6
Refrigerant piping
Liquid side/ Gas side mm φ6.4/φ12.7 φ6.4/φ12.7
Max. pipe length m 25 25
Max. difference in level m 15 15
Ambient temp. ℃ cooling:18~43; heating:-7~24
cooling: 18~43; heating:-7~24
