Midea MOV-96CN1-C

Air-cooled Package DM13-01.01.16en
20 Service manual
Gross Cooling Capacity (kW)
Outdoor DB(°C)
40.60 46.10 51.70
Indoor WB(°C)
16.10 19.40 22.80 16.10 19.40 22.80 16.10 19.40
22.80
CFM DB(°C)
TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI
2000
23.9 17.3 14.2 7.94 18.9 10.7 8.18 20.1 4.6 8.33 15.8 13.0 8.13 17.3 9.8 8.39 18.5 4.3 8.64 15.5 12.7 8.51 16.8 9.5 8.87 17.9 4.1 9.12
26.7 17.6 16.0 7.96 19.2 12.5 8.20 20.5 8.8 8.35 16.1 14.7 8.15 17.6 11.4 8.41 18.8 8.1 8.66 15.8 14.4 8.53 17.1 11.1 8.89 18.2 7.9 9.14
29.4 18.0 17.3 7.98 19.6 16.1 8.22 20.9 12.5 8.37 16.5 15.8 8.17 18.0 14.7 8.43 19.2 11.4 8.68 16.2 15.5 8.55 17.5 14.3 8.91 18.6 11.1 9.16
32.2 18.3 18.0 8.00 20.0 18.2 8.24 21.4 15.7 8.39 16.8 16.5 8.19 18.3 16.7 8.45 19.6 14.4 8.70 16.5 16.2 8.57 17.8 16.2 8.93 19.0 14.0 9.19
2300
23.9 17.9 15.0 8.14 19.5 11.2 8.38 20.7 4.9 8.53 16.4 13.8 8.33 17.9 10.3 8.59 19.1 4.5 8.84 16.1 13.6 8.71 17.4 10.1 9.07 18.5 4.4 9.32
26.7 18.3 16.9 8.16 19.9 14.1 8.40 21.2 9.3 8.55 16.8 15.5 8.35 18.3 12.9 8.61 19.5 8.5 8.86 16.5 15.2 8.73 17.8 12.6 9.09 18.9 8.3 9.34
29.4 18.6 18.3 8.18 20.2 17.0 8.42 21.6 13.2 8.57 17.1 16.8 8.37 18.6 15.6 8.63 19.8 12.1 8.88 16.8 16.5 8.75 18.1 15.2 9.11 19.2 11.7 9.36
32.2 19.0 19.0 8.20 20.7 19.1 8.44 22.0 16.4 8.59 17.4 17.4 8.39 19.0 17.6 8.65 20.2 15.1 8.90 17.1 17.1 8.77 18.5 17.1 9.14 19.6 14.6 9.39
2500
23.9 18.4 16.9 7.84 20.0 12.5 8.23 21.2 5.5 8.23 16.9 15.5 8.57 18.4 11.5 8.83 19.6 5.1 9.08 16.6 15.3 8.95 17.9 11.2 9.31 19.0 4.9 9.56
26.7 18.8 18.8 7.86 20.4 15.7 8.10 21.7 10.4 8.25 17.3 17.3 8.59 18.8 14.4 8.85 20.0 9.5 9.10 17.0 17.0 8.97 18.3 14.0 9.33 19.4 9.3 9.58
29.4 19.1 19.1 7.88 20.8 19.0 8.12 22.1 14.6 8.27 17.6 17.6 8.61 19.1 17.5 8.87 20.3 13.5 9.12 17.3 17.3 8.99 18.6 17.1 9.35 19.7 13.1 9.60
32.2 19.5 19.5 7.90 21.2 19.2 8.14 22.5 18.3 8.29 17.9 17.9 8.63 19.5 17.7 8.89 20.8 16.9 9.15 17.6 17.6 9.01 19.0 17.3 9.38 20.1 16.4 9.63
2800
23.9 18.9 16.7 8.69 20.4 12.2 8.93 21.7 5.3 9.08 17.4 15.4 8.88 18.9 11.3 9.14 20.0 4.9 9.39 17.1 15.1 9.26 18.4 11.0 9.62 19.5 4.8 9.87
26.7 19.3 18.5 8.71 20.9 15.3 8.95 22.2 10.1 9.10 17.8 17.1 8.90 19.3 14.2 9.16 20.5 9.3 9.41 17.5 16.8 9.28 18.8 13.8 9.64 19.9 9.0 9.89
29.4 19.6 19.6 8.73 21.3 18.5 8.97 22.6 14.3 9.12 18.1 18.1 8.92 19.6 17.1 9.18 20.9 13.2 9.43 17.8 17.8 9.30 19.1 16.6 9.66 20.3 12.8 9.91
32.2 20.0 20.0 8.75 21.7 20.9 8.99 23.0 17.9 9.15 18.5 18.5 8.94 20.0 19.3 9.21 21.3 16.5 9.46 18.2 18.2 9.33 19.5 18.8 9.69 20.7 16.0 9.94
Notes:
1. DB = Dry Bulb Temperature (°C), WB = Wet Bulb Temperature (°C)
4. TGC = Total Cooling Capacity (kW)
5. SHC = Sensible Heating Capacity (kW)
6. PI = Power Input (kW)
