Or
Foam seal C
(Non-adhesive type)
Foam seal C
(Non-adhesive type)
Or
2 Screws
Security Bracket
3. Cut the non-adhesive foam seal C strip to match the width(or height) of the window. Insert the seal
between the glass and the window frame to prevent air and insects from getting into the room.
5. Insert the Anti-hot Air Inlet Adaptor into the air hose, then rotate 90° clockwise for hung window.
For Sliding window insert the Exhuast Adaptor to the air hose.
4. If desired, install the security bracket with 2 screws as shown.
2 Screws
Security
Bracket
Page 13
Installation
Instructions
Or
Or
6. Insert the air hose into the hole of the window slider for hung window. For Sliding Window the window
slider hole is not in the center, so the Exhuast Adaptor is installed away from the wall. Then Insert the
Exhuast Adaptor into the hole of the window slider.
1 2
1 2
To Next Page
