Midea MRC-36CWN1-V10 User Manual

MCAC-RTSM-2014-03 R410A Rooftop Package Unit 60Hz
11
Model
MRC-36CWN1-V10
(A)
MRC-48CWN1-V10
(A)
MRC-60CWN1-V10
(A)
MRC-60CWN1-X10
(A)
Power supply
V/Ph /Hz
208~230/1/60
208~230/1/60
208~230/1/60
208~230/3/60
Cooling
Capacity
Btu/h
36000
48000
60000
60000
SEER
Btu/h.W
10
10
10
10
Electrical
data
Max. input consumption
KW
4.5
7.5
8.8
7.8
Max. power input
A
24.8
41.5
48.4
25.5
Compress
or
Model
APA032KAB
ABA051KAB
ABA054KAE
ZP57K3E-TF5-522
Type
Scroll
Scroll
Scroll
Scroll
Brand
LG
LG
LG
Copeland
Rated current(RLA)
A
14
21.5
23
16.3
Locked rotor Amp(LRA)
A
70
125
120
155
Thermal protector
239℉~257℉
(115℃-125℃)
239℉~257℉
(115℃-125℃)
239℉~257℉
(115℃-125℃)
275℉(135℃)
Refrigerant oil
ml
800
1300
1300
1591
Indoor fan
motor
Model
YDK270-6E
YDK400-6E
YDK600-6E
YDK600-6E
Type
AC motor
AC motor
AC motor
AC motor
Brand
Welling/DaYang
Welling/DaYang
Welling/DaYang
Welling/DaYang
Output
HP
1/3
1/2
4/5
4/5
Rated current
A
1.41
2.08
2.33
2.33
Capacitor
uF
10
20
20
20
RPM
r/min
400
890
990
990
Indoor fan
Material
Metal
Metal
Metal
Metal
Type
Centrifugal fan
Centrifugal fan
Centrifugal fan
Centrifugal fan
Diameter
Inch(mm)
11.1(282)
11.1(282)
11.1(282)
11.1(282)
Height
Inch(mm)
10.7(272)
10.7(272)
10.7(272)
10.7(272)
Indoor coil
Number of rows
3
3
4
4
Tube pitch(a)x row
pitch(b)
Inch(mm)
0.8×0.5(21×13.37)
0.8×0.5(21×13.37)
0.8×0.5(21×13.37)
0.8×0.5(21×13.37)
Fin spacing
Inch(mm)
5.9(1.5)
5.9(1.5)
5.9(1.5)
5.9(1.5)
Fin type
Hydrophilic
aluminum
Hydrophilic
aluminum
Hydrophilic
aluminum
Hydrophilic
aluminum
Tube outside diameter
and type
Inch(mm)
Φ1/16(Φ7)
Φ1/16(Φ7)
Φ1/16(Φ7)
Φ1/16(Φ7)
Type
Inner grooved tube
Inner grooved tube
Inner grooved tube
Inner grooved tube
Coil length x height
Inch(mm)
16.6×28(421×714)
16.6×28(421×714)
16.6×28(421×714)
16.6×28(421×714)
Number of circuits
8
8
8
8
ESP
Pa
50
50
50
50
Indoor fan air flow
CFM
1380
1400
1450
1450
Outdoor
Model
YDK180-6B
YDK180-6B
YDK180-6B
YDK180-6B
