Midea MRC-36CWN1-V10 User Manual

R410A Rooftop Package Unit 60Hz MCAC-RTSM-2014-03
12
fan motor
Type
AC motor
AC motor
AC motor
AC motor
Brand
Welling
Welling
Welling
Welling
Output
HP
1/3
1/3
1/3
1/3
Rated current
A
2
2
2
2
Capacitor
uF
12
12
12
12
RPM
r/min
1075
1075
1075
1075
Outdoor
fan
material
Alnico
Alnico
Alnico
Alnico
Type
Axial flow fan
Axial flow fan
Axial flow fan
Axial flow fan
Diameter
Inch(mm)
22.7(550)
22.7(550)
22.7(550)
22.7(550)
Height
Inch(mm)
4(102.5)
4(102.5)
4(102.5)
4(102.5)
Outdoor
coil
Number of rows
1
1.7
2
2
Tube pitch(a)x row pitch(b)
Inch(mm)
0.8×0.5(21×13.37)
0.8×0.5(21×13.37)
0.8×0.5(21×13.37)
0.8×0.5(21×13.37)
Fin spacing
Inch(mm)
5.9(1.5)
5.9(1.5)
5.9(1.5)
5.9(1.5)
Fin type (code)
Hydrophilic
aluminum
Hydrophilic
aluminum
Hydrophilic
aluminum
Hydrophilic
aluminum
Tube outside diameter and
type
Inch(mm)
Φ1/16(Φ7)
Φ1/16(Φ7)
Φ1/16(Φ7)
Φ1/16(Φ7)
Type
Inner grooved tube
Inner grooved tube
Inner grooved tube
Inner grooved tube
Coil length x height
Inch(mm)
1513×756
1480×756
1480×756
1480×756
Number of circuits
1
1
1
1
Dimension
Net (W×H×D)
mm
1116×830×744
1116×830×744
1116×830×744
1116×830×744
Packing(W×H×D)
mm
1152×855×765
1152×855×765
1152×855×765
1152×855×765
Weight
Net/Gross weight
Kg
132/135
141/144
151/154
151/154
Charged refrigerant
R410A/1600g
R410A/2200g
R410A/2750g
R410A/2550g
Optional Controller
KJR-23B
KJR-23B
KJR-23B
KJR-23B
Operation temp.
℃
17~30
17~30
17~30
17~30
℉
62.6~86
62.6~86
62.6~86
62.6~86
Ambient
temp.
Cooling
℃
18~46
18~46
18~46
18~46
℉
64.4~114.8
64.4~114.8
64.4~114.8
64.4~114.8
Filter
Type
Nylon
Nylon
Nylon
Nylon
Quantity
Pieces
1
1
1
1
Size (W×H×D)
mm
197x670x10
197x670x10
197x670x10
197x670x10
Shipping
Qty'Per 20'/40'/40'HQ
Pieces
30/62/91
30/62/91
30/62/91
30/62/91
Note:
The data are based on the following conditions:
Cooling: Indoor Temperature 26.7°C(80°F) DB / 19.4°C(67°F) WB; - Outdoor Temperature 35°C(95°F) DB.

Midea MRC-36CWN1-V10 Specifications
