DM16‐01.01.27en RooftopClimaCreatorseries
54 Service manual
MRCT-085CWN1-R(C)
Cooling capacity: (Continued)
Gross Cooling Capacity
Ambient DB(°C) 48 51.7
Indoor WB(°C) 16.1 19.4 22.8 16.1 19.4 22.8
CFM DB(°C) TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
2,450
23.9 60.8 59.3 9742.1 75.5 43.1 9903.4 89.0 23.0 11425.7 56.2 54.8 10237.3 67.8 38.4 10208.0 81.8 21.8 12043.8
26.7 62.3 60.9 9988.8 77.3 60.1 10175.1 91.1 39.4 11775.8 57.6 56.2 10505.7 69.5 53.8 10497.9 83.7 36.7 12440.5
29.4 64.0 62.4 10335.5 79.2 76.4 11043.7 93.3 55.7 12183.5 59.0 57.7 10835.5 71.2 68.6 11422.4 85.7 51.5 12883.2
32.2 65.6 64.1 10632.2 81.1 78.2 11389.6 95.5 71.7 12583.6 60.6 59.1 11152.5 72.9 70.4 11769.1 87.8 66.1 13286.6
3,500
23.9 63.3 60.7 9839.9 77.2 46.4 9967.5 89.7 23.6 11456.1 58.4 56.1 10325.0 69.3 41.4 10265.3 82.5 22.3 12070.8
26.7 64.9 62.2 10090.0 80.5 64.4 10300.0 91.9 41.8 11806.2 59.9 57.5 10596.8 72.9 57.7 10632.9 84.5 39.0 12470.9
29.4 66.5 63.9 10436.7 81.0 79.2 11111.2 94.1 59.3 12217.2 61.4 59.0 10930.0 73.3 71.1 11503.4 86.5 54.8 12913.5
32.2 68.3 65.5 10736.8 82.9 81.1 11457.1 96.4 76.3 12617.3 63.0 60.5 11247.0 74.6 72.9 11833.2 88.5 70.3 13317.0
4,200
23.9 65.9 64.1 9944.5 79.2 49.4 10048.5 90.3 24.3 11479.7 60.8 59.2 10419.5 71.2 44.1 10339.5 83.0 22.9 12091.0
26.7 67.6 65.8 10194.6 81.1 69.5 10323.6 92.5 44.2 11829.8 62.4 60.7 10694.6 73.1 62.3 10639.6 85.0 41.0 12491.1
29.4 69.3 67.4 10544.7 83.1 80.8 11194.7 94.7 62.3 12240.8 64.4 62.2 11044.7 74.7 72.7 11560.7 87.1 57.6 12937.2
32.2 71.0 69.1 10844.8 85.1 83.7 11544.8 97.0 80.8 12640.9 65.5 63.8 11344.8 76.5 75.3 11910.8 89.1 74.4 13337.3
Notes:
1. All capacities are gross and have not considered indoor fan heat. To obtain net cooling capacity subtract indoor fan heat;
2. TC = Total Capacity (Unit: 1,000Btu/h); SC = Sensible Capacity (Unit: 1,000Btu/h).
