Rooftop ClimaCreator series DM16-01.01.27en
Service manual 55
MRCT-100CWN1-R(C)
Cooling capacity:
Gross Cooling Capacity
Ambient DB(°C) 29.4 35
Indoor WB(°C) 16.1 19.4 22.8 16.1 19.4 22.8
CFM DB(°C) TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
3,300
23.9 106.6 92.5 9374.6 119.1 68.9 10455.4 123.6 43.4 10837.3 98.5 88.4 8753.4 114.4 66.5 10317.4 122.5 42.0 10828.7
26.7 109.0 94.6 9686.2 121.8 87.9 10790.6 126.4 60.8 11187.5 100.8 90.5 9073.6 117.0 85.7 10471.4 125.2 61.3 11178.9
29.4 111.4 96.7 10043.3 124.4 104 11165.0 129.1 75.6 11570.6 103.0 92.4 9499.7 119.5 105 10923.4 127.9 77.5 11648.2
32.2 113.7 98.7 10557.7 127.0 121 11698.0 131.7 91.3 12111.9 105.1 94.4 10014.1 122.0 119 11534.1 130.6 93.8 12198.2
4,100
23.9 109.6 95.5 9633.5 122.1 71.9 10714.3 126.6 46.4 11096.2 101.5 91.4 9012.2 117.4 69.5 10576.2 125.5 45.0 11087.6
26.7 112.0 97.6 9945.0 124.8 90.9 11049.5 129.4 63.8 11446.4 103.8 93.5 9332.4 120.0 88.7 10710.2 128.2 64.3 11437.8
29.4 114.4 99.7 10302.2 127.4 107 11423.9 132.1 78.6 11829.4 106.0 95.4 9758.6 122.5 108 11182.3 130.9 80.5 11907.1
32.2 116.7 102 10816.6 130.0 124 11956.9 134.7 94.3 12370.8 108.1 97.4 10273.0 125.0 122 11792.9 133.6 96.8 12457.1
4,600
23.9 112.5 102 9883.7 123.3 74.3 10817.8 127.0 47.0 11130.7 104.6 97.9 9279.7 121.2 73.0 10904.1 125.8 45.9 11113.4
26.7 115.0 104 10203.9 126.0 93.2 11153.0 129.8 64.7 11480.9 106.9 100 9599.9 125.9 93.7 11239.3 128.5 65.6 11463.6
29.4 117.4 106 10561.0 128.6 112 11527.4 132.5 80.2 11863.9 109.2 102 10034.7 127.5 113 11613.7 131.2 83.3 11933.0
32.2 119.8 109 11084.0 131.2 128 12060.4 135.2 95.7 12413.9 111.4 104 10557.7 129.1 123 12146.7 133.9 101 12483.0
Notes:
1. All capacities are gross and have not considered indoor fan heat. To obtain net cooling capacity subtract indoor fan heat;
2. TC = Total Capacity (Unit: 1,000Btu/h); SC = Sensible Capacity (Unit: 1,000Btu/h).
