Midea MRCT-200CWN1-R(C)

Rooftop ClimaCreator series DM16-01.01.27en
Service manual 61
MRCT-150CWN1-R(C)
Cooling capacity:
Gross Cooling Capacity
Ambient DB(°C) 29.4 35
Indoor WB(°C) 16.1 19.4 22.8 16.1 19.4 22.8
CFM DB(°C) TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
5,500
23.9 163.5 131 15041.6 183.2 105 15388.1 193.5 72.1 15888.1 153.3 125 15898.0 171.6 99.8 16270.9 188.7 68.9 16770.9
26.7 165.6 156 15321.7 185.5 128 15668.2 197.3 96.8 16168.2 157.1 150 16148.1 174.2 123 16551.0 191.1 93.1 17051.0
29.4 173.0 166 16002.1 187.7 150 16298.6 199.9 117 16798.6 164.6 160 16678.5 176.7 146 16843.8 193.6 115 17343.8
32.2 182.9 176 16225.2 190.4 173 16521.7 202.4 137 17021.7 175.6 170 17201.6 180.4 169 17366.9 196.3 135 17866.9
7,000
23.9 167.9 139 15191.6 188.6 109 15538.1 195.7 73.5 16038.1 155.2 133 16048.0 178.9 104 16420.9 190.1 70.4 16920.9
26.7 171.6 166 15471.7 190.0 133 15818.2 198.5 99.0 16318.2 162.0 157 16298.1 180.0 129 16701.0 192.2 96.3 17201.0
29.4 179.1 174 16152.1 191.2 157 16448.6 202.3 120 16948.6 171.8 167 16828.5 182.8 154 16993.8 195.3 118 17493.8
32.2 188.9 183 16375.2 192.6 180 16671.7 204.7 139 17171.7 181.6 176 17351.6 184.1 179 17516.9 198.7 140 18016.9
7,800
23.9 169.8 146 15491.6 190.9 111 15838.1 198.2 74.8 16338.1 160.7 140 16348.0 185.0 128 16720.9 191.8 71.7 17220.9
26.7 174.2 167 15771.7 192.5 166 16118.2 201.0 99.9 16618.2 164.5 160 16598.1 187.3 164 17001.0 194.3 97.9 17501.0
29.4 185.2 178 16452.1 193.7 172 16748.6 203.4 122 17248.6 176.7 171 17128.5 187.8 171 17293.8 196.9 121 17793.8
32.2 193.8 186 16675.2 195.3 188 16971.7 206.0 144 17471.7 186.5 181 17651.6 188.9 187 17816.9 198.2 144 18316.9
Notes:
1. All capacities are gross and have not considered indoor fan heat. To obtain net cooling capacity subtract indoor fan heat;
2. TC = Total Capacity (Unit: 1,000Btu/h); SC = Sensible Capacity (Unit: 1,000Btu/h).
