DM16‐01.01.27en RooftopClimaCreatorseries
62 Service manual
MRCT-150CWN1-R(C)
Cooling capacity: (Continued)
Gross Cooling Capacity
Ambient DB(°C) 40.6 46.1
Indoor WB(°C) 16.1 19.4 22.8 16.1 19.4 22.8
CFM DB(°C) TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
5,500
23.9 142.6 120 16610.8 163.5 94.5 17014.1 185.6 65.5 17514.1 117.6 102 17211.6 141.0 85.6 18401.2 160.6 49.3 18901.2
26.7 146.4 141 16840.9 166.1 118 17144.2 187.0 89.2 17644.2 122.6 119 17696.7 143.5 101 18531.3 163.2 72.9 19031.3
29.4 153.9 148 17071.3 169.8 141 17637.0 188.3 112 18137.0 135.0 131 18182.1 144.8 124 19224.1 165.8 96.3 19724.1
32.2 166.3 160 17794.4 171.2 166 18360.1 189.6 133 18860.1 147.4 143 19160.2 148.4 147 19974.2 167.1 119 20474.2
7,000
23.9 147.5 128 16760.8 164.7 109 17164.1 188.1 66.9 17664.1 121.3 109 17361.6 142.2 90.5 18551.2 165.6 50.7 19051.2
26.7 151.3 145 16990.9 168.5 124 17294.2 189.4 92.3 17794.2 128.8 123 17846.7 146.0 107 18681.3 168.1 77.1 19181.3
29.4 163.7 157 17221.3 173.5 150 17787.0 190.8 116 18287.0 141.2 135 18332.1 148.5 133 19374.1 169.4 101 19874.1
32.2 171.2 164 17944.4 176.1 171 18510.1 193.3 139 19010.1 153.6 147 19310.2 151.1 151 20124.2 170.8 124 20624.2
7,800
23.9 150.0 135 17060.8 173.3 103 17464.1 190.6 68.2 17964.1 125.0 115 17661.6 150.8 104 18851.2 169.2 53.6 19351.2
26.7 156.2 152 17290.9 175.9 130 17594.2 191.9 95.3 18094.2 127.7 124 18146.7 153.4 121 18981.3 170.6 79.6 19481.3
29.4 169.8 165 17521.3 178.5 157 18087.0 193.2 119 18587.0 138.3 134 18632.1 157.1 147 19674.1 171.9 106 20174.1
32.2 178.8 173 18244.4 181.0 176 18810.1 194.5 143 19310.1 159.7 155 19610.2 161.5 165 20424.2 173.2 131 20924.2
Notes:
1. All capacities are gross and have not considered indoor fan heat. To obtain net cooling capacity subtract indoor fan heat;
2. TC = Total Capacity (Unit: 1,000Btu/h); SC = Sensible Capacity (Unit: 1,000Btu/h).
