Rooftop ClimaCreator series DM16-01.01.27en
Service manual 63
MRCT-150CWN1-R(C)
Cooling capacity: (Continued)
Gross Cooling Capacity
Ambient DB(°C) 48 51.7
Indoor WB(°C) 16.1 19.4 22.8 16.1 19.4 22.8
CFM DB(°C) TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
5,500
23.9 114.6 98.7 17039.4 140.5 85.1 18421.9 157.6 46.3 18921.9 112.6 97.3 16867.3 135.0 81.8 18766.8 154.0 46.9 19266.8
26.7 119.6 116 17779.5 142.9 100 18552.0 160.2 69.9 19052.0 117.4 114 17862.4 137.5 96.3 18896.9 156.4 69.6 19396.9
29.4 132.0 128 18520.0 144.1 123 19419.8 162.8 93.3 19919.8 129.3 125 18857.8 138.8 119 19864.4 158.9 92.1 20364.4
32.2 144.4 140 19753.1 147.6 147 20199.9 164.1 116 20699.9 139.6 135 20345.9 141.3 141 20664.5 160.2 114 21164.5
7,000
23.9 118.3 106 17189.4 141.7 90.0 18571.9 162.6 47.7 19071.9 116.1 104 17017.3 136.2 86.5 18916.8 158.7 48.2 19416.8
26.7 125.8 120 17929.5 145.4 107 18702.0 165.1 74.1 19202.0 123.3 119 18012.4 139.9 103 19046.9 161.2 73.6 19546.9
29.4 138.2 132 18670.0 147.8 132 19569.8 166.4 97.6 20069.8 135.2 131 19007.8 142.3 127 20014.4 162.4 96.2 20514.4
32.2 150.6 144 19903.1 150.3 150 20349.9 167.8 121 20849.9 147.2 142 20495.9 144.8 140 20814.5 163.7 119 21314.5
7,800
23.9 122.0 112 17489.4 150.3 103 18871.9 166.2 50.6 19371.9 119.7 110 17317.3 144.5 91.3 19216.8 162.2 51.1 19716.8
26.7 124.7 121 18229.5 152.8 121 19002.0 167.6 76.6 19502.0 128.0 124 18312.4 147.0 108 19346.9 163.5 76.0 19846.9
29.4 135.3 131 18970.0 156.4 142 19869.8 168.9 103 20369.8 141.2 137 19307.8 150.6 133 20314.4 164.8 101 20814.4
32.2 156.7 152 20203.1 160.7 164 20649.9 170.2 128 21149.9 153.1 148 20795.9 154.6 150 21114.5 166.1 126 21614.5
Notes:
1. All capacities are gross and have not considered indoor fan heat. To obtain net cooling capacity subtract indoor fan heat;
2. TC = Total Capacity (Unit: 1,000Btu/h); SC = Sensible Capacity (Unit: 1,000Btu/h).
