Midea MRCT-200CWN1-R(C)

Rooftop ClimaCreator series DM16-01.01.27en
Service manual 67
MRCT-200CWN1-R(C)
Cooling capacity:
Gross Cooling Capacity
Ambient DB(°C) 29.4 35
Indoor WB(°C) 16.1 19.4 22.8 16.1 19.4 22.8
CFM DB(°C) TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
7,000
23.9 216.2 174 20278.5 242.2 138 21474.3 225.9 95.5 22772.2 202.7 166 20646.9 227.0 132 21842.7 249.5 91.3 23140.6
26.7 218.8 206 20347.6 245.2 169 21613.6 260.8 128 22857.5 207.6 198 20786.3 230.2 163 22052.3 252.6 123 23296.1
29.4 228.6 222 20902.9 247.9 198 21796.9 264.0 155 23029.6 217.4 211 21341.6 233.5 193 22235.5 255.7 152 23468.2
32.2 241.4 234 20918.6 251.3 229 22002.3 267.3 180 23085.1 231.8 225 21357.3 238.2 224 22441.0 259.1 179 23523.8
8,800
23.9 222.1 183 20598.6 249.4 145 22043.4 258.8 97.3 22865.2 205.3 175 20957.4 236.5 138 22402.1 251.3 93.2 23223.9
26.7 226.8 219 20638.7 251.2 175 22163.4 262.4 131 22940.7 214.1 206 21077.4 240.0 171 22602.0 254.1 127 23379.4
29.4 236.5 229 20919.0 252.6 208 22235.5 267.3 158 23157.3 227.0 218 21357.7 241.4 203 22674.2 258.0 156 23596.0
32.2 249.4 242 21006.7 254.3 238 22324.4 270.3 183 23212.8 239.8 230 21445.4 243.0 237 22763.1 262.4 185 23651.5
10,300
23.9 224.5 193 20425.4 252.5 147 22246.7 262.1 99.1 22788.8 212.5 185 21069.5 244.7 193 22890.8 253.6 95.0 23432.9
26.7 230.2 223 20902.9 254.4 180 22518.7 265.6 132 23096.2 217.4 211 21341.6 246.5 231 22957.4 256.9 130 23534.9
29.4 244.7 237 20992.0 255.9 214 22607.6 268.7 161 23198.2 233.5 226 21430.7 248.1 233 23046.2 260.1 160 23636.9
32.2 255.9 248 21080.3 257.8 248 22679.8 272.0 190 23308.2 246.3 239 21519.0 249.4 246 23118.4 261.7 190 23746.9
Notes:
1. All capacities are gross and have not considered indoor fan heat. To obtain net cooling capacity subtract indoor fan heat;
2. TC = Total Capacity (Unit: 1,000Btu/h); SC = Sensible Capacity (Unit: 1,000Btu/h).
