DM16‐01.01.27en RooftopClimaCreatorseries
68 Service manual
MRCT-200CWN1-R(C)
Cooling capacity: (Continued)
Gross Cooling Capacity
Ambient DB(°C) 40.6 46.1
Indoor WB(°C) 16.1 19.4 22.8 16.1 19.4 22.8
CFM DB(°C) TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
7,000
23.9 188.6 158 22346.6 216.2 125 22790.6 245.5 86.7 24988.5 178.9 158 23928.7 192.7 120 24372.7 218.7 71.7 26993.8
26.7 193.5 188 22486.0 219.5 156 23000.2 247.1 118 25144.0 185.4 180 24068.1 196.0 139 24582.3 222.0 103 27149.3
29.4 203.2 197 23041.2 224.4 187 23183.4 248.7 148 25316.1 201.6 196 24623.4 197.6 170 24765.5 225.2 133 27321.4
32.2 219.5 213 23057.0 226.0 219 23388.9 250.4 176 25371.6 217.9 212 24639.1 200.9 201 24971.0 226.9 164 27376.9
8,800
23.9 195.1 169 22657.1 217.9 144 23350.0 248.7 88.7 25071.8 183.7 167 24239.2 194.4 126 24932.1 225.2 73.5 27077.1
26.7 200.0 194 22777.1 222.7 164 23549.9 250.4 122 25227.2 193.5 188 24359.2 199.2 148 25132.0 228.5 108 27232.6
29.4 216.2 210 23057.4 229.2 198 23622.1 252.0 153 25443.8 209.7 204 24639.5 202.5 181 25204.2 230.1 139 27449.1
32.2 226.0 219 23145.1 232.5 209 23710.9 255.2 184 25499.3 226.0 219 24727.2 205.7 206 25293.1 231.7 170 27504.6
10,300
23.9 198.4 179 22769.1 229.2 136 23838.6 252.0 90.3 25280.7 188.6 176 24351.3 205.7 150 25420.8 230.1 77.4 27286.0
26.7 206.5 200 23041.2 232.5 172 23905.3 253.6 126 25382.7 200.0 194 24623.4 209.0 172 25487.4 231.7 112 27388.0
29.4 224.4 218 23130.3 235.7 208 23994.1 255.2 157 25484.7 217.9 212 24712.5 213.9 207 26687.4 233.4 146 27490.0
32.2 239.0 232 23218.6 239.0 239 24066.3 256.9 188 25594.7 234.1 227 24800.8 217.1 208 26759.6 235.0 180 27600.0
Notes:
1. All capacities are gross and have not considered indoor fan heat. To obtain net cooling capacity subtract indoor fan heat;
2. TC = Total Capacity (Unit: 1,000Btu/h); SC = Sensible Capacity (Unit: 1,000Btu/h).
