Midea MRCT-200CWN1-R(C)

RooftopClimaCreatorseries DM16‐01.01.27en
Service manual 85
MRCT-150CWN1-R(C)
ESP
(Pa)
N 0 0.25 0.5 0.75 1 1.25 1.5 1.75 2
X 0.5 1 1.5 2 2.5 3 3.5 4 4.5
0
Fan speed (rpm)
/ / 1,008 999 989 979 969 959 949
Power input (W)
/ / 5,146 4,968 4,790 4,575 4,360 4,155 3,950
Air flow (CFM)
/ / 7,928 7,867 7,805 7,686 7,566 7,452 7,338
25
Fan speed (rpm)
/ / 1,014 1,003 991 983 974 964 953
Power input (W)
/ / 5,043 4,824 4,605 4,418 4,230 4,025 3,820
Air flow (CFM)
/ / 7,791 7,691 7,592 7,473 7,353 7,239 7,124
50
Fan speed (rpm)
/ 1,022 1,020 1,006 993 986 979 968 957
Power input (W)
/ 4,954 4,940 4,680 4,420 4,260 4,100
3,895 3,690
Air flow (CFM)
/ 7,700 7,653 7,516 7,379 7,259 7,139
7,025 6,910
75
Fan speed (rpm)
1,031 1,026 1,022 1,009 995 989 982 971 960
Power input (W)
4,870 4,810 4,750 4,495 4,240
4,088 3,935 3,745 3,555
Air flow (CFM)
7,622 7,529 7,436 7,313 7,191
7,048 6,904 6,790 6,675
100
Fan speed (rpm)
1,035 1,028 1,021
1,008
995 988 982 971 959
Power input (W)
4,770 4,665 4,560
4,310
4,060 3,915 3,770 3,595 3,420
Air flow (CFM)
7,475 7,347 7,219
7,111
7,002 6,836 6,669 6,554 6,439
125
Fan speed (rpm)
1,050 1,044 1,039 1,026 1,013 1,006 998 990 981
Power input (W)
4,510 4,440 4,370 4,123 3,875 3,760 3,645 3,465 3,285
Air flow (CFM)
7,113 7,046 6,979 6,844 6,708 6,571 6,434 6,297 6,159
150
Fan speed (rpm)
1,060 1,056 1,052 1,039 1,026 1,021 1,015 1,005 995
Power input (W)
4,350 4,290 4,230 4,005 3,780 3,695 3,610 3,410 3,210
Air flow (CFM)
6,899 6,863 6,828 6,679 6,531 6,411 6,291 6,134 5,976
175
Fan speed (rpm)
1,070 1,065 1,060 1,049 1,039 1,032 1,025 1,017 1,008
Power input (W)
4,170 4,078 3,985 9,808 3,630 3,518 3,405 3,248 3,090
Air flow (CFM)
6,658 6,609 6,559 6,419 6,279 6,161 6,043 5,859 5,675
