Midea MRCT-200CWN1-R(C)

DM16‐01.01.27en  RooftopClimaCreatorseries
86 Service manual
Continued: MRCT-150CWN1-R(C)
ESP
(Pa)
N 0 0.25 0.5 0.75 1 1.25 1.5 1.75 2
X 0.5 1 1.5 2 2.5 3 3.5 4 4.5
200
Fan speed (rpm)
1,082 1,074 1,067 1,059 1,051 1,044 1,036 1,028 1,020
Power input (W)
3,990 3,865 3,740 3,610 3,480 3,340 3,200 3,085 2,970
Air flow (CFM)
6,418 6,354 6,291 6,159 6,027 5,911 5,794 5,584 5,375
225
Fan speed (rpm)
1,089 1,082 1,074 1,065 1,056 1,048 1,040 1,033 1,027
Power input (W)
3,855 3,728 3,600 3,455 3,310 3,180 3,050 2,928 2,805
Air flow (CFM)
6,194 6,108 6,022 5,879 5,736 5,600 5,464 5,269 5,075
250
Fan speed (rpm)
1,097 1,089 1,082 1,072 1,061 1,053 1,044 1,038 1,033
Power input (W)
3,720 3,590 3,460 3,300 3,140 3,020 2,900 2,770 2,640
Air flow (CFM)
5,971 5,862 5,754 5,600 5,446 5,289 5,133 4,954 4,776
275
Fan speed (rpm)
1,104 1,095 1,086 1,076 1,065 / / / /
Power input (W)
3,595 3,438 3,280 3,115 2,950 / / / /
Air flow (CFM)
5,705 5,585 5,464 5,308 5,151 / / / /
300
Fan speed (rpm)
1,112 / / / / / / / /
Power input (W)
3,470 / / / / / / / /
Air flow (CFM)
5,439 / / / / / / / /
325
Fan speed (rpm)
1,112 / / / / / / / /
Power input (W)
3,470 / / / / / / / /
Air flow (CFM)
5,439 / / / / / / / /
Notes:
1. Legend: X – Regulation space of motor pulley (mm); N: Number of turns; ESP: External static pressure (in.w.g);
2: Pulley pitch factory set point: The table, No. of turns (N) = 5;
3. Bold data is the performance testing set point;
4. Shading data are rated airflow.
