Midea MRCT-200CWN1-R(C)

RooftopClimaCreatorseries DM16‐01.01.27en
Service manual 89
MRCT-200CWN1-R(C)
ESP
(Pa)
N 0 0.25 0.5 0.75 1 1.25 1.5 1.75 2 2.25 2.5 2.75 3
X 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 5.5 6 6.5
0
Fan speed (rpm)
/ / / / 1,194 1,181 1,168 1,154 1,140 1,127 1,113 1,098 1,081
Power input (W)
/ / / / 6,951 6,710 6,468 6,266 6,063 5,831 5,599 5,422 5,188
Air flow (CFM)
/ / / / 11,210 11,104 10,997 10,872 10,746 10,623 10,499 10,306 10,078
25
Fan speed (rpm)
/ / / / 1,195 1,182 1,169 1,155 1,141 1,128 1,114 1,100 1,083
Power input (W)
/ / / / 6,756 6,531 6,306 6,103 5,901 5,671 5,442 5,255 5,057
Air flow (CFM)
/ / / / 10,982 10,890 10,798 10,668 10,539 10,398 10,258 10,068 9,892
50
Fan speed (rpm)
/ / / 1,214 1,196 1,183 1,170 1,156 1,142 1,129 1,115 1,101 1,084
Power input (W)
/ / / 6,944 6,561 6,352 6,143 5,941 5,738 5,512 5,285 5,088 4,926
Air flow (CFM)
/ / / 10,877 10,754 10,676 10,599 10,465 10,332 10,174 10,016 9,829 9,705
75
Fan speed (rpm)
/ / / 1,214 1,197 1,184 1,171 1,157 1,143 1,130 1,116 1,102 1,085
Power input (W)
/ / / 6,738 6,390 6,180 5,970 5,754 5,539 5,328 5,118 5,069 4,748
Air flow (CFM)
/ / / 10,628 10,540 10,453 10,367 10,207 10,047 9,898 9,749 9,807 9,403
100
Fan speed (rpm)
/ 1,240 1,228 1,215 1,198 1,185 1,172 1,158 1,145 1,131 1,117 1,103 1,087
Power input (W)
/ 6,941 6,765 6,532 6,218 6,008 5,797 5,568 5,339 5,145 4,950 5,049 4,570
Air flow (CFM)
/ 10,582 10,491 10,378 10,326 10,230 10,135 9,948 9,761 9,622 9,483 9,785 9,102
125
Fan speed (rpm)
/ 1,241 1,230 1,215 1,199 1,186 1,173 1,159 1,146 1,131 1,117 1,105
1,091
Power input (W)
/ 6,753 6,659 6,367 6,068 5,866 5,663 5,441 5,218 5,013 4,808 4,570
4,351
Air flow (CFM)
/ 10,357 10,349 10,170 10,113 10,017 9,922 9,753 9,584 9,435 9,285 9,024
8,815
150
Fan speed (rpm)
1,258 1,242 1,230 1,216 1,202 1,189 1,175 1,162 1,149 1,134 1,120 1,105 1,091
Power input (W)
6,736 6,565 6,360 6,158 5,820 5,611 5,401 5,180 4,958 4,769
4,579 4,327 4,141
Air flow (CFM)
10,287 10,132 10,049 9,952 9,818 9,692 9,566 9,395 9,224 9,069
8,915 8,599 8,418
