Midea MRCT-200CWN1-R(C)

DM16‐01.01.27en  RooftopClimaCreatorseries
90 Service manual
Continued: MRCT-200CWN1-R(C)
ESP
(Pa)
N 0 0.25 0.5 0.75 1 1.25 1.5 1.75 2 2.25 2.5 2.75 3
X 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 5.5 6 6.5
175
Fan speed (rpm)
1,261 1,244 1,232 1,218 1,204 1,190 1,177 1,163 1,149 1,135 1,121 1,106 1,093
Power input (W)
6,511 6,332 6,169 5,929 5,607 5,391 5,175 4,953
4,731 4,545 4,358 4,107 3,925
Air flow (CFM)
10,042 9,864 9,794 9,650 9,524 9,377 9,231 9,046
8,861 8,699 8,537 8,243 8,045
200
Fan speed (rpm)
1,263 1,245 1,233 1,221 1,205 1,192 1,179 1,164 1,150 1,136 1,123 1,106 1,094
Power input (W)
6,285 6,099 5,977 5,700 5,394 5,172 4,949
4,727 4,504 4,321 4,137 3,887 3,709
Air flow (CFM)
9,798 9,597 9,540 9,347 9,230 9,063 8,896
8,697 8,497 8,328 8,158 7,887 7,672
225
Fan speed (rpm)
1,264 1,248 1,235 1,222 1,207 1,194 1,181 1,166 1,152 1,138 1,124 1,110 1,096
Power input (W)
6,046 5,871 5,696 5,451 5,160
4,923 4,686 4,461 4,237 4,049 3,861 3,624 3,433
Air flow (CFM)
9,505 9,301 9,183 9,019 8,877
8,693 8,508 8,291 8,074 7,871 7,669 7,387 7,138
250
Fan speed (rpm)
1,265 1,251 1,237 1,224 1,209 1,196 1,183 1,169 1,154 1,140 1,126 1,113 1,099
Power input (W)
5,807 5,643
5,415 5,201 4,925 4,674 4,422 4,196 3,969 3,777 3,585 3,361 3,157
Air flow (CFM)
9,212 9,004
8,826 8,691 8,524 8,322 8,120 7,885 7,650 7,415 7,180 6,887 6,605
275
Fan speed (rpm)
1,267 1,253 1,239 1,226 1,211 1,198 1,185 1,171 1,157 1,144 1,130 1,117 1,094
Power input (W)
5,523 5,350 5,120 4,872 4,585 4,322 4,059 3,812 3,564 3,331 3,098 2,800 2,662
Air flow (CFM)
8,831 8,594 8,380 8,204 8,010 7,740 7,470 7,173 6,876 6,487 6,099 5,562 5,395
300
Fan speed (rpm)
1,269 1,254 1,242 1,228 1,213 1,201 1,188 1,174 1,160 1,147 1,134 1,120 1,088
Power input (W)
5,238 5,056 4,825 4,542 4,245 3,971 3,696 3,428 3,159 2,885 2,611 2,239 2,167
Air flow (CFM)
8,450 8,184 7,933 7,717 7,495 7,157 6,819 8,460 6,102 5,560 5,018 4,237 4,186
325
Fan speed (rpm)
1,272 1,258 1,245 1,233 1,218 1,206 1,193 / / / / / /
Power input (W)
4,892 4,650 4,334 3,987 3,707 3,334 2,961 / / / / / /
Air flow (CFM)
7,955 7,559 7,136 6,775 6,406 5,820 5,234 / / / / / /
