Midea MRCT-200CWN1-R(C)

RooftopClimaCreatorseries DM16‐01.01.27en
Service manual 91
Continued: MRCT-200CWN1-R(C)
ESP
(Pa)
N 0 0.25 0.5 0.75 1 1.25 1.5 1.75 2 2.25 2.5 2.75 3
X 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 5.5 6 6.5
350
Fan speed (rpm)
1,276 1,262 1,248 1,235 1,223 / / / / / / / /
Power input (W)
4,546 4,243 3,842 3,731 3,169 / / / / / / / /
Air flow (CFM)
7,459 6,935 6,339 6,285 5,318 / / / / / / / /
375
Fan speed (rpm)
1,280 1,267 1,254 / / / / / / / / / /
Power input (W)
3,982 3,457 3,371 / / / / / / / / / /
Air flow (CFM)
6,465 5,433 5,387 / / / / / / / / / /
400
Fan speed (rpm)
1,284 / / / / / / / / / / / /
Power input (W)
3,417 / / / / / / / / / / / /
Air flow (CFM)
5,471 / / / / / / / / / / / /
Notes:
1. Legend: X – Regulation space of motor pulley (mm); N: Number of turns; ESP: External static pressure (in.w.g);
2: Pulley pitch factory set point: The table, No. of turns (N) = 5;
3. Bold data is the performance testing set point;
4. Shading data are rated airflow.
