Midea MRCT-200CWN1-R(C)

DM16‐01.01.27en  RooftopClimaCreatorseries
92 Service manual
MRCT-250CWN1-R(C)
ESP
(Pa)
N 0 0.25 0.5 0.75 1 1.25 1.5 1.75 2 2.25 2.5 2.75 3
X 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 5.5 6 6.5
0
Fan speed (rpm)
1,075 1,059 1,044 1,034 1,026 1,009 1,002 985 973 963 934 939 925
Power input (W)
6,962 6,840 6,589 6,382 6,068 5,930 5,651 5,544 5,232 5,085 4,765 4,893 4,734
Air flow (CFM)
12,304 12,345 12,115 12,068 11,907 11,717 11,587 11,472 11,269 11,177 10,868 10,894 10,757
25
Fan speed (rpm)
1,075 1,060 1,041 1,035 1,027 1,010 1,003 986 974 964 935 939 926
Power input (W)
6,750 6,663 6,363 6,203 5,914 5,736 5,487 5,374 5,065 4,905 4,632 4,740 4,597
Air flow (CFM)
12,052 12,092 11,849 11,797 11,645 11,431 11,322 11,191 10,982 10,879 10,572 10,610 10,471
50
Fan speed (rpm)
1,074 1,061 1,038 1,036 1,028 1,011 1,004 987 975 965 936 940 927
Power input (W)
6,538 6,485 6,137 6,023 5,759 5,541 5,323 5,203 4,898 4,724
4,498 4,587 4,459
Air flow (CFM)
11,801 11,838 11,583 11,527 11,383 11,144 11,058 10,909 10,695 10,581
10,276 10,326 10,185
75
Fan speed (rpm)
1,075 1,062 1,040 1,036 1,029 1,011 1,004 987 976 966 937 941 928
Power input (W)
6,391 6,301 5,903 5,842 5,573 5,329 5,152 5,019
4,698 4,524 4,304 4,410 4,282
Air flow (CFM)
11,575 11,558 11,249 11,218 11,055 10,820 10,745 10,585
10,345 10,217 9,914 9,964 9,825
100
Fan speed (rpm)
1,075 1,063 1,041 1,036 1,030 1,012 1,005 988 977 967 937 942 928
Power input (W)
6,243 6,117 5,668 5,660 5,387 5,116 4,980
4,834 4,498 4,324 4,110 4,233 4,104
Air flow (CFM)
11,350 11,278 10,915 10,910 10,728 10,496 10,432
10,260 9,995 9,853 9,552 9,602 9,465
125
Fan speed (rpm)
1,076 1,063 1,044 1,037 1,030 1,013 1,005 989 979 968 938 943 929
Power input (W)
6,089 5,904 5,425 5,441
5,178 4,900 4,790 4,626 4,292 4,114 3,928 4,040 3,911
Air flow (CFM)
11,019 10,945 10,566 10,567
10,361 10,123 10,054 9,870 9,598 9,432 9,155 9,168 9,021
150
Fan speed (rpm)
1,077 1,063
1,047
1,037 1,031 1,015 1,005 990 980 969 939 944 930
Power input (W)
5,934 5,690
5,181
5,222 4,969 4,683 4,600 4,418 4,085 3,904 3,746 3,846 3,717
Air flow (CFM)
10,688 10,612
10,217
10,224 9,994 9,749 9,677 9,480 9,201 9,010 8,758 8,735 8,577
