Midea MRCT-200CWN1-R(C)

RooftopClimaCreatorseries DM16‐01.01.27en
Service manual 93
Continued: MRCT-250CWN1-R(C)
ESP
(Pa)
N 0 0.25 0.5 0.75 1 1.25 1.5 1.75 2 2.25 2.5 2.75 3
X 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 5.5 6 6.5
175
Fan speed (rpm)
1,077 1,064 1,047 1,038 1,032 1,015 1,006 991 981 969 939 944 931
Power input (W)
5,613 5,449 4,984 4,995 4,746 4,455 4,382 4,203 3,862 3,683 3,548 3,645 3,512
Air flow (CFM)
10,300 10,229 9,839 9,828 9,590 9,294 9,245 9,031 8,703 8,496 8,259 8,225 8,064
200
Fan speed (rpm)
1,078 1,065 1,048 1,039 1,033 1,016 1,006 992 982 969 940 945 932
Power input (W)
5,292 5,207 4,786 4,768 4,522 4,226 4,163 3,987 3,638 3,462 3,349 3,443 3,307
Air flow (CFM)
9,913 9,847 9,462 9,432 9,186 8,838 8,812 8,581 8,206 7,983 7,760 7,715 7,551
225
Fan speed (rpm)
1,079 1,066 1,051 1,040 1,034 1,017 1,007 993 983 970 941 946 932
Power input (W)
5,294 4,968 4,527 4,522 4,299 3,990 3,958 3,758 3,408 3,240 3,135 3,203 3,078
Air flow (CFM)
9,875 9,378 8,936 8,922 8,670 8,306 8,296 8,037 7,615 7,383 7,169 7,025 6,863
250
Fan speed (rpm)
1,080 1,067 1,053 1,042 1,034 1,018 1,008 994 984 970 942 947 933
Power input (W)
5,295 4,728 4,267 4,275 4,076 3,753 3,753 3,528 3,177 3,018 2,921 2,962 2,849
Air flow (CFM)
9,837 8,910 8,410 8,412 8,154 7,775 7,780 7,492 7,024 6,784 6,578 6,335 6,175
275
Fan speed (rpm)
1,082 1,068 1,050 1,042 1,035 1,019 1,009 995 985 971 942 948 934
Power input (W)
4,879 4,488 4,013 4,034 3,825 3,496 3,486 3,341 2,975 2,803 2,717 2,792 2,530
Air flow (CFM)
8,972 8,391 7,852 7,864 7,575 7,096 7,053 6,824 6,335 5,996 5,844 5,744 5,204
300
Fan speed (rpm)
1,084 1,070 1,047 1,043 1,035 1,021 1,010 995 986 973 943 949 935
Power input (W)
4,463 4,248 3,759 3,793 3,574 3,239 3,219 3,153 2,773 2,587 2,512 2,621 2,210
Air flow (CFM)
8,107 7,871 7,293 7,316 6,996 6,418 6,325 6,156 5,647 5,209 5,110 5,152 4,234
325
Fan speed (rpm)
1,084 1,072 1,054 1,046 1,036 1,023 1,010 997 986 / / / /
Power input (W)
4,219 3,996 3,636 3,538 3,313 3,089 3,219 2,818 2,773 / / / /
Air flow (CFM)
7,663 7,324 6,813 6,603 6,221 5,896 6,325 5,316 5,647 / / / /
