Midea MRCT-200CWN1-R(C)

DM16‐01.01.27en  RooftopClimaCreatorseries
94 Service manual
Continued: MRCT-250CWN1-R(C)
ESP
(Pa)
N 0 0.25 0.5 0.75 1 1.25 1.5 1.75 2 2.25 2.5 2.75 3
X 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 5.5 6 6.5
350
Fan speed (rpm)
1,085 1,073 1,061 1,050 1,038 1,025 1,011 / / / / / /
Power input (W)
3,975 3,744 3,513 3,282 3,051 2,940 3,024 / / / / / /
Air flow (CFM)
7,219 6,776 6,332 5,889 5,445 5,375 5,815 / / / / / /
375
Fan speed (rpm)
1,087 1,074 1,062 / / / / / / / / / /
Power input (W)
3,708 3,474 3,241 / / / / / / / / / /
Air flow (CFM)
6,428 5,990 5,551 / / / / / / / / / /
400
Fan speed (rpm)
1,088 / / / / / / / / / / / /
Power input (W)
3,440 / / / / / / / / / / / /
Air flow (CFM)
5,637 / / / / / / / / / / / /
Notes:
1. Legend: X – Regulation space of motor pulley (mm); N: Number of turns; ESP: External static pressure (in.w.g);
2: Pulley pitch factory set point: The table, No. of turns (N) = 5;
3. Bold data is the performance testing set point;
4. Shading data are rated airflow.
