Midea MRCT-200CWN1-R(C)

RooftopClimaCreatorseries DM16‐01.01.27en
Service manual 95
MRCT-300CWN1-R(C)
ESP
(Pa)
N 0 0.25 0.5 0.75 1 1.25 1.5 1.75 2 2.25 2.5 2.75 3
X 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 5.5 6 6.5
0
Fan speed (rpm)
/ / / / / / 1,106 1,090 1,074 1,053 1,032 1,027 1,022
Power input (W)
/ / / / / / 8,203 7,899 7,595 7,256 6,917 6,894 6,872
Air flow (CFM)
/ / / / / / 13,393 13,210 13,026 12,794 12,563 12,499 12,434
25
Fan speed (rpm)
/ / / / 1,133 1,133 1,106 1,090 1,074 1,053 1,032 1,027 1,022
Power input (W)
/ / / / 9,142 9,142 8,010 7,702 7,394 7,078 6,761 6,736 6,710
Air flow (CFM)
/ / / / 13,735 13,735 13,243 13,044 12,845 12,605 12,366 12,307 12,248
50
Fan speed (rpm)
/ / / / 1,135 1,135 1,108 1,092 1,076 1,055 1,034 1,029 1,023
Power input (W)
/ / / / 8,664 8,664 7,736 7,427 7,118 6,828 6,537 6,509 6,480
Air flow (CFM)
/ / / / 13,304 13,304 12,902 12,690 12,479 12,234 11,990 11,937 11,884
75
Fan speed (rpm)
/ / / / 1,137 1,137 1,109 1,094 1,078 1,056 1,035 1,030 1,025
Power input (W)
/ / / / 8,425 8,425 7,490 7,160 6,831 9,544 6,258 6,241 6,225
Air flow (CFM)
/ / / / 13,089 13,089 12,619 12,384 12,149 11,897 11,644 11,591 11,539
100
Fan speed (rpm)
/ / 1,153 1,146 1,138 1,138 1,110 1,095 1,080 1,058 1,036 1,031 1,026
Power input (W)
/ / 9,127 8,545 8,186 8,186 7,244 6,893 6,543 6,261 5,978 5,974 5,970
Air flow (CFM)
/ / 13,410 12,993 12,873 12,873 12,336 12,078 11,820 11,558 11,296 11,245 11,193
125
Fan speed (rpm)
/ / 1,155 1,148 1,140 1,140 1,112 1,097 1,083 1,060 1,038 1,033 1,028
Power input (W)
/ / 8,920 8,330 7,963 7,963 7,007 6,642 6,278 6,012 5,746 5,733 5,720
Air flow (CFM)
/ / 13,149 12,713 12,576 12,576 12,002 11,730 11,457 11,193 10,929 10,849 10,769
150
Fan speed (rpm)
1,172 1,165 1,157 1,150 1,142 1,142 1,113 1,099 1,085 1,062 1,039 1,035 1,030
Power input (W)
9,645 9,015 8,712 8,069 7,741 7,080 6,770 6,391 6,012 5,763 5,513 5,492 5,470
Air flow (CFM)
13,274 12,898 12,887 12,386 12,278 11,362 11,669 11,381 11,094 10,827 10,560 10,451 10,342
