Midea MRCT-200CWN1-R(C)

DM16‐01.01.27en  RooftopClimaCreatorseries
96 Service manual
Continued: MRCT-300CWN1-R(C)
ESP
(Pa)
N 0 0.25 0.5 0.75 1 1.25 1.5 1.75 2 2.25 2.5 2.75 3
X 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 5.5 6 6.5
175
Fan speed (rpm)
1,172 1,166 1,158 1,152 1,144 1,144 1,114 1,100 1,087 1,064 1,041 1,036 1,032
Power input (W)
9,364 8,711 8,385 7,748 7,426 7,426 6,467 6,083 5,699 5,468
5,236 5,210 5,184
Air flow (CFM)
12,944 12,550 12,522 12,006 11,884 11,884 11,246 10,916 10,587 10,317
10,047 9,928 9,809
200
Fan speed (rpm)
1,173 1,167 1,159 1,153 1,145 1,145 1,116 1,102 1,088 1,065 1,042 1,038 1,033
Power input (W)
9,083 8,407 8,058 7,415 7,111 7,111 6,164 5,775
5,387 5,173 4,959 4,928 4,897
Air flow (CFM)
12,615 12,175 12,156 11,586 11,489 11,489 10,822 10,450
10,078 9,804 9,530 9,402 9,273
225
Fan speed (rpm)
1,174 1,168 1,161 1,155 1,147 1,147 1,117 1,104 1,091 1,067 1,044 1,039 1,035
Power input (W)
8,884 8,145 7,732 7,083 6,772 6,772
5,812 5,408 5,004 4,804 4,603 4,562 4,520
Air flow (CFM)
12,356 11,835 11,735 11,139 11,016 11,016
10,298 9,875 9,452 9,175 8,898 8,708 8,518
250
Fan speed (rpm)
1,176 1,172 1,162 1,156 1,148 1,148 1,119 1,106 1,093 1,069 1,046 1,041 1,036
Power input (W)
8,686 7,877 7,406 6,744 6,433 6,433 5,460 5,041 4,622 4,436 4,250 4,197 4,145
Air flow (CFM)
12,097 11,466 11,313 10,604 10,546 10,546 9,773 9,298 8,823 8,542 8,262 8,009 7,756
275
Fan speed (rpm)
1,187 1,176
1,168
1,159 1,149 1,149 1,121 1,108 1,095 1,071 1,047 1,042 1,038
Power input (W)
8,462 7,587
7,067
6,394 6,081 6,081 5,095 4,722 4,348 4,159 3,970 3,834 3,697
Air flow (CFM)
11,693 10,973
10,835
10,015 9,895 9,895 8,955 8,500 8,044 7,732 7,420 7,014 6,608
300
Fan speed (rpm)
1,182 1,175 1,166 1,159 1,150 1,150 1,123 1,109 1,096 1,072 1,048 1,044 1,039
Power input (W)
8,114 7,246
6,711 6,082 5,721 5,721 4,730 4,402 4,075 3,883 3,691 3,469 3,247
Air flow (CFM)
11,270 10,508
10,253 9,488 9,195 9,195 8,138 7,701 7,265 6,919 6,574 6,010 5,447
325
Fan speed (rpm)
1,185 1,178 1,169 1,161 1,152 1,138 1,124 / / / / / /
Power input (W)
7,721
6,884 6,379 5,782 5,453 4,990 4,527 / / / / / /
Air flow (CFM)
10,729
9,983 9,745 8,998 8,723 8,211 7,700 / / / / / /
