Midea MRCT-200CWN1-R(C)

RooftopClimaCreatorseries DM16‐01.01.27en
Service manual 97
Continued: MRCT-300CWN1-R(C)
ESP
(Pa)
N 0 0.25 0.5 0.75 1 1.25 1.5 1.75 2 2.25 2.5 2.75 3
X 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 5.5 6 6.5
350
Fan speed (rpm)
1,188 1,182 1,171 1,164 1,154 1,139 1,125 / / / / / /
Power input (W)
7,328 6,237 6,046 5,347 5,185 4,755 4,324 / / / / / /
Air flow (CFM)
10,187 8,913 9,238 8,209 8,250 7,756 7,262 / / / / / /
375
Fan speed (rpm)
1,191 1,183 1,173 1,165 1,155 1,140 1,126 / / / / / /
Power input (W)
7,114 6,130 5,596 5,121 4,916 4,576 4,236 / / / / / /
Air flow (CFM)
9,916 8,778 8,439 7,810 7,715 7,353 6,991 / / / / / /
400
Fan speed (rpm)
1,195 1,185 1,175 1,166 1,156 1,141 1,127 / / / / / /
Power input (W)
6,899 6,022 5,146 4,896 4,647 4,397 4,148 / / / / / /
Air flow (CFM)
9,645 8,643 7,640 7,410 7,180 6,951 6,721 / / / / / /
Notes:
1. Legend: X – Regulation space of motor pulley (mm); N: Number of turns; ESP: External static pressure (in.w.g);
2: Pulley pitch factory set point: The table, No. of turns (N) = 5;
3. Bold data is the performance testing set point;
4. Shading data are rated airflow.
