Service manual
- 8 -
MSG-09CR
MSG-09HR
MSG-12CR
Ph-V-Hz
1, 220-240V~,50Hz
1, 220-240V~,50Hz
1, 220-240V~,50Hz
Capacity Btu/h 9000 9000 12000
Input W 960 960 1230
Rated current A 4.5 4.5 5.7
EER Btu/w.h 9.4 9.4 9.8
Capacity Btu/h
-----
10000
-----
Input W
-----
980
-----
Rated current A
-----
4.4
-----
COP W/W
-----
10.2
-----
A SUNISO 400 7 9
A 25 25 25
Model PH165X1CY-4DG2 2P18S225ANK PH200X2C-4FT
Type Rotary Rotary Rotary
Brand GD Toshiba GD Matsushita GD Toshiba
Capacity Btu/h 9380 9920 11840
Input W 900 970 1135
Rated current(RLA) A 4.1 4.5 5.2
Locked rotor Amp(LRA) A 24 24 25
Thermal protector
UP3QE0591-T61(internal)
External
（
MRA98745
）
Internal
Capacitor uF 25 30 25
Refrigerant oil ml SUNISO 400 SUNISO 350 440
Model
RPG13H RPG13H
RPG13H
Brand WELLING WELLING Welling
Input W
36.5 36.5
36.5
Capacitor uF
1.2
μ
F/450V
1.2
μ
F/450V
1.2
Speed(hi/mi/lo) r/min 1100/1020/950 1100/1020/950 1350
m3/h
450/420/390 450/420/390
550/500/460
dB(A)
37/34/31 37/34/31
41/ 38 /34
Model
YDK24-6T YDK24-6T YDK24-6
Brand WELLING WELLING WELLING
Input W 55 55 72
Capacitor uF
2.5
μ
F/450V
2.5
μ
F/450V
2.5
μ
F/450V
Speed r/min 800 800 850
m
3
/h
1500 1500 1800
dB(A) 50 50 52
g 600 650 730
MPa
2.6 2.6
2.6
Liquid side/ Gas side mm
Ф
6.35/
Ф
9.53
Ф
6.35/
Ф
9.53
Ф
6.35/
Ф
12.7
Max. refrigerant pipe length m 10 10 10
Max. difference in level m 5 5 5
℃
17-30 17-30
17-30
℃
18-45 -7 - 45 18-45
m
2
14-21 14-21 18-26
Model
Power supply
Cooling
Heating
Max. current
Starting current
Compressor
Indoor
fan motor
Indoor air flow (Hi/Mi/Lo)
Indoor noise level (Hi/Mi/Lo)
Outdoor
fan motor
Outdoor air flow
Operation temp
Ambient temp
Application area
Outdoor noise level
Refrigerant type R410A
Design pressure
Refrigerant
piping
Note:
The noise date is base on hemi-anechoic chamber, during actual operation; these values are normally somewhat
different as a result of ambient condition.
The above design and specifications are subject to change without prior notice for product improvement.
