Midea MSG-12HR - Page 13

Service manual
- 9 -
MSG-12HR
MSG-16CR
MSG-16HR
Ph-V-Hz
1, 220-240V~,50Hz
220-240V~,50Hz
220-240V~,50Hz
Capacity Btu/h 12000 16000 16000
Input W 1230
1620 1600
Rated current A 5.7
7.5 7.4
EER Btu/w.h 9.8 9.9
10.0,2.9
Capacity Btu/h 13000
----- 17500
Input W 1290
----- 1650
Rated current A 6
----- 7.6
COP W/W 9.8
-----
3.1
A 9.1 9.8 10
A 26
36 36
Model PH225X2C-4FT
PH290X2C-4FT1 PH290X2C-4FT1
Type Rotary Rotary Rotary
Brand GD Toshiba GD Toshiba GD Toshiba
Capacity Btu/h 13610 17435 17435
Input W 1305 1670 1670
Rated current(RLA) A 6.1 8 8
Locked rotor Amp(LRA) A 26 41.2 41.2
Thermal protector External Internal Internal
Capacitor uF 35 35 35
Refrigerant oil ml 430 520 520
Model RPG13H
RPG25 RPG25
Brand Welling WELLING WELLING
Input W 36.5
53 53
Capacitor uF 1.2
1.5uF/450V 1.5uF/450V
Speed(hi/mi/lo) r/min 1350 1180 1180
m3/h 550/500/460
750/710/650 750/710/650
dB(A) 41/ 38 /34
41/38/35 41/38/35
Model
YDK24-6 YDK36-6 YDK36-6
Brand WELLING WELLING WELLING
Input W 72
96 96
Capacitor uF
2.5
μ
F/450V
2.5
μ
F/450V
2.5
μ
F/450V
Speed r/min 850
900 900
m
3
/h
1800 1900 1900
dB(A) 52
53 53
g 820
1110 1370
MPa 2.6
2.6 2.6
Liquid side/ Gas side mm
Ф
6.35/
Ф
12.7
Ф
6.35/
Ф
12.7
Ф
6.35/
Ф
12.7
Max. refrigerant pipe length m 10 10 10
Max. difference in level m 5 5 5
℃
17-30
17-30 17-30
℃
-7 - 45 18-45 -7 - 45
m
2
18-26 25-35 25-35
Model
Power supply
Cooling
Heating
Max. current
Starting current
Compressor
Indoor
fan motor
Indoor air flow (Hi/Mi/Lo)
Indoor noise level (Hi/Mi/Lo)
Outdoor
fan motor
Outdoor air flow
Operation temp
Ambient temp
Application area
Outdoor noise level
Refrigerant type R410A
Design pressure
Refrigerant
piping
Note:
The noise date is base on hemi-anechoic chamber, during actual operation; these values are normally somewhat
different as a result of ambient condition.
The above design and specifications are subject to change without prior notice for product improvement.
