Service manual
- 11 -
MSG-36CR MSG-36HR
Ph-V-Hz 3, 380-420V~, 50Hz3, 380-420V~, 50Hz
Capacity Btu/h
35000 35000
Input W
4120 4120
Rated current A
6.5 6.5
EER Btu/w.h
8.5 8.5
Capacity Btu/h -----
38000
Input W -----
4100
Rated current A -----
6.4
COP W/W
----- 9.3
A
11 11
A
48 48
Model
ZR34KH-TFD-522 ZR34KH-TFD-522
Type
Scroll Scroll
Brand
Copeland Copeland
Capacity Btu/h
39000 39000
Input W
3480 3480
Rated current(RLA) A
6.3 6.3
Locked rotor Amp(LRA) A
43/48 43/48
Thermal protector
34HM224 34HM224
Capacitor uF
----- -----
Refrigerant oil ml SONTEX 200LT 1242 SONTEX 200LT 1242
Model
YDK50-4E YDK50-4E
Brand
Welling Welling
Input W
85/80/77 85/80/77
Capacitor uF
3 3
Speed(hi/mi/lo) r/min
1260/1150/990 1260/1150/990
m3/h
1350/1200/1050 1350/1200/1050
dB(A)
49/46/42 49/46/42
Model
YDK100-6 YDK100-6
Brand
Welling Welling
Input W
169 169
Capacitor uF
5 5
Speed r/min
900 900
m
3
/h
3000 3000
dB(A)
59 59
g
2400 2450
MPa
2.6 2.6
Liquid side/ Gas side mm
Φ
9.52/
Φ
16
Φ
9.52/
Φ
16
Max. refrigerant pipe length m
25 25
Max. difference in level m
10 10
℃
17-30 17-30
℃
18-45 -7 - 45
m
2
60~78 60~78
Model
Power supply
Cooling
Heating
Max. current
Starting current
Compressor
Indoor
fan motor
Indoor air flow (Hi/Mi/Lo)
Indoor noise level (Hi/Mi/Lo)
Outdoor
fan motor
Outdoor air flow
Operation temp
Ambient temp
Application area
Outdoor noise level
Refrigerant type R410A
Design pressure
Refrigerant
piping
Note:
The noise date is base on hemi-anechoic chamber, during actual operation; these values are normally somewhat
different as a result of ambient condition.
The above design and specifications are subject to change without prior notice for product improvement.
