Midea MSMBB-12HRFN1-MU0W

Maintenance and
Disassembly
 Page 63 
Procedure Illustration
1) Disconnect the connector for fan motor
from the electronic control board (see
CJ_ODU_INV_013).
2) Remove the fixing screws of the fan motor
(4 screws) (see CJ_ODU_INV_014).
3) Remove the fan motor.
CJ_ODU_INV_013
CJ_ODU_INV_014
Note: This section is for reference only. Actual unit appearance may vary.
