10. Capacity table
10.1 MSV1-09HRDN1
COOLING OUTDOOR TEMPERATURE DRY
Indoor Conditions 21ºC 25ºC 30ºC 35ºC 40ºC 45ºC 50ºC
Total capacity kW 2.87 3.00 2.60 2.34 1.98 1.70 1.53
Sensitive capacity kW 1.84 1.91 2.03 1.99 1.65 1.46 1.32
21ºC D
15ºC W
Input kW. 0.701 0.72 0.80 0.86 0.89 0.98 1.16
Total capacity kW 2.98 3.15 2.85 2.45 2.30 1.95 1.74
Sensitive capacity kW 1.84 2.01 2.23 2.11 1.93 1.72 1.50
24ºC D
17ºC W
Input kW. 0.72 0.73 0.82 0.90 0.92 1.01 1.17
Total capacity kW 3.13 3.20 2.98 2.58 2.60 2.34 2.03
Sensitive capacity kW 2.04 2.15 2.30 1.96 2.23 2.09 1.73
27ºC D
19ºC W
Input kW. 0.75 0.78 0.85
0.76 0.96 1.04 1.19
Total capacity kW 3.29 3.33 3.12 3.05 2.80 2.62 2.32
Sensitive capacity kW 2.17 2.15 2.43 2.56 2.38 2.33 2.05
32ºC D
23ºC W
Input kW. 0.78 0.80 0.86 1.00 1.01 1.08 1.23
HEATING OUTDOOR CONDITIONS
Indoor Conditions
24ºC D
18ºCW
12ºC D
11ºCW
7ºC D
6ºC W
4ºC D
3ºCW
0ºC D
-1ºCW
-5ºC D
-6ºC W
-7ºCD
-8ºC W
-15ºC D
-16ºC W
Capacity kW 3.5 4.11 4.10 3.80 3.49 3.12 3.01 1.72
15ºC
Input kW. 0.958 1.53 1.57 1.56 1.51 1.39 1.37 1.30
Capacity kW 3.45 4.10 4.05 3.70 3.48 3.11 2.99 1.70
18ºC
Input kW. 0.96 1.55 1.58 1.60 1.52 1.40 1.38 1.32
Capacity kW 3.44 4.05 2.87 3.69 3.47 3.00 2.86 1.69
20ºC
Input kW. 0.965 1.60 0.79 1.63 1.54 1.42 1.40 1.35
Capacity kW 3.435 4.00 3.932 3.65 3.47 2.97 2.81 1.68
22ºC
Input kW. 0.98 1.65
1.64 1.67 1.58 1.45 1.43 1.38
Capacity kW 3.4 3.95 3.85 3.60 3.43 2.89 2.79 1.67
27ºC
Input kW. 0.99 1.69 1.69 1.70 1.61 1.50 1.48 1.40
10.2 MSV1-12HRDN1
COOLING OUTDOOR TEMPERATURE DRY
Indoor
Conditions
21ºC 25ºC 30ºC 35ºC 40ºC 45ºC 50ºC
Total capacity kW 3.187 3.48 3.30 3.01 2.81 2.38 2.16
Sensitive capacity kW 2.23 2.40 2.38 2.28 2.25 2.10 1.90
21ºC D
15ºC W
Input kW. 0.924 1.08 1.18 1.30 1.39 1.45 1.59
Total capacity kW 3.579 3.76 3.65 3.43 2.98 2.70 2.44
Sensitive capacity kW 2.505 2.61 2.66 2.61 2.41 2.35 2.20
24ºC D
17ºC W
Input kW. 0.957 1.10 1.19 1.33 1.41 1.49 1.61
Total capacity kW 3.879 4.09 3.90 3.50 3.19 2.99 2.79
Sensitive capacity kW 2.792 2.86 2.89 2.80 2.58 2.60 2.45
27ºC D
19ºC W
Input kW. 0.979 1.11 1.20
1.07 1.45 1.51 1.60
Total capacity kW 4.087 4.32 4.02 3.80 3.62 3.40 3.28
Sensitive capacity kW 3.168 3.80 3.01 3.07 3.11 2.96 2.89
32ºC D
23ºC W
Input kW. 0.989 1.12 1.25 1.40 1.48 1.55 1.68
