Air-cooled Package DM13-01.01.16en

26 Service manual

Gross Cooling Capacity (kW)

Outdoor DB(°C) 40.60 46.10 51.70

Indoor WB(°C) 16.10 19.40 22.80 16.10 19.40 22.80 16.10 19.40

22.80

CFM DB(°C) TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI

2440

23.9 22.0 18.0 10.83 23.5 13.3 11.07 24.8 5.7 11.22 20.5 16.8 11.02 22.0 12.4 11.28 23.1 5.3 11.53 19.4 15.9 11.52 20.7 11.7 11.88 21.8 5.0 12.13

26.7 22.4 20.4 10.86 24.0 15.5 11.10 25.3 10.9 11.25 20.9 19.0 11.05 22.4 14.5 11.31 23.6 10.2 11.56 19.8 18.0 11.55 21.1 13.7 11.91 22.2 9.6 12.16

29.4 22.8 22.0 10.89 24.5 20.1 11.13 25.8 15.4 11.28 21.3 20.5 11.08 22.8 18.7 11.34 24.1 14.3 11.59 20.2 19.4 11.58 21.5 17.6 11.94 22.7 13.5 12.19

32.2 23.3 22.8 10.91 25.0 22.7 11.16 26.3 19.4 11.31 21.7 21.3 11.11 23.3 21.2 11.37 24.6 18.1 11.62 20.6 20.2 11.61 22.0 20.0 11.97 23.1 17.0 12.22

2740

23.9 22.6 19.0 11.03 24.1 14.0 11.27 25.4 6.0 11.42 21.1 17.7 11.22 22.6 13.0 11.48 23.7 5.6 11.73 20.0 16.8 11.72 21.3 12.3 12.08 22.4 5.3 12.33

26.7 23.0 21.3 11.06 24.6 17.5 11.30 25.9 11.4 11.45 21.5 19.9 11.25 23.0 16.3 11.51 24.2 10.6 11.76 20.4 18.9 11.75 21.7 15.4 12.11 22.8 10.0 12.36

29.4 23.5 23.0 11.09 25.1 21.1 11.33 26.4 16.1 11.48 22.0 21.5 11.28 23.5 19.7 11.54 24.7 15.1 11.79 20.8 20.4 11.78 22.2 18.6 12.14 23.3 14.2 12.39

32.2 24.0 24.0 11.12 25.6 23.7 11.36 27.0 20.1 11.51 22.4 22.4 11.31 24.0 22.2 11.57 25.2 18.8 11.82 21.3 21.3 11.81 22.6 20.9 12.17 23.8 17.7 12.42

3000

23.9 23.1 21.2 11.27 24.6 15.4 11.66 25.9 6.7 11.66 21.6 19.8 11.46 23.1 14.4 11.72 24.2 6.3 11.97 20.5 18.8 11.96 21.8 13.6 12.32 22.9 5.9 12.57

26.7 23.5 23.5 11.30 25.1 19.3 11.54 26.4 12.6 11.69 22.0 22.0 11.49 23.3 18.1 11.75 24.7 11.8 12.00 20.9 20.9 11.99 22.2 17.1 12.35 23.3 11.2 12.60

29.4 24.0 24.0 11.33 25.6 23.5 11.57 26.9 17.8 11.72 22.5 22.5 11.52 24.0 22.0 11.78 25.2 16.7 12.03 21.3 21.3 12.02 22.7 20.8 12.38 23.8 15.8 12.63

32.2 24.5 24.5 11.36 26.1 23.8 11.60 27.5 22.3 11.75 22.9 22.9 11.55 24.5 22.2 11.81 25.7 20.9 12.06 21.8 21.8 12.05 23.1 21.0 12.41 24.3 19.7 12.66

3240

23.9 23.5 20.8 11.58 25.1 15.0 11.82 26.4 6.5 11.97 22.1 19.5 11.77 23.5 14.1 12.03 24.7 6.1 12.28 21.0 18.6 12.27 22.3 13.3 12.63 23.4 5.7 12.88

26.7 24.0 23.1 11.61 25.6 18.8 11.85 26.9 12.2 12.00 22.5 21.7 11.80 24.0 17.7 12.06 25.2 11.5 12.31 21.4 20.6 12.30 22.7 16.7 12.66 23.8 10.8 12.91

29.4 24.5 24.5 11.64 26.1 22.7 11.88 27.5 17.4 12.03 23.0 23.0 11.83 24.5 21.3 12.09 25.7 16.3 12.34 21.9 21.9 12.33 23.2 20.2 12.69 24.3 15.4 12.94

32.2 25.0 25.0 11.67 26.7 25.6 11.91 28.0 21.7 12.06 23.4 23.4 11.86 25.0 24.0 12.12 26.2 20.3 12.37 22.3 22.3 12.36 23.6 22.7 12.72 24.8 19.2 12.97

Notes:

1. DB = Dry Bulb Temperature (°C), WB = Wet Bulb Temperature (°C)

4. TGC = Total Cooling Capacity (kW)

5. SHC = Sensible Heating Capacity (kW)

6. PI = Power Input (kW)
