DM13-01.01.16en Air-cooled Package
Service manual 27
7.1.5 MTA-120CRN1
Gross Cooling Capacity (kW)
Outdoor DB(°C) 29.40 35.00
Indoor WB(°C) 16.10 19.40 22.80 16.10 19.40 22.80
CFM DB(°C) TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI TGC SHC PI
3200
23.9 32.0 25.0 10.99 34.6 19.5 11.19 36.0 8.3 11.32 31.4 25.7 11.42 33.4 18.9 11.65 34.7 8.0 11.79
26.7 33.1 28.5 11.02 35.3 22.8 11.22 36.7 15.8 11.35 32.0 29.1 11.45 34.1 22.1 11.68 35.4 15.3 11.82
29.4 34.3 31.1 11.05 36.0 29.5 11.25 37.4 22.3 11.38 32.6 31.4 11.48 34.8 28.5 11.71 36.1 21.5 11.85
32.2 35.5 34.8 11.08 36.7 33.4 11.28 38.2 28.1 11.41 33.3 32.6 11.51 35.5 32.2 11.74 36.8 27.1 11.88
3500
23.9 33.0 26.4 11.19 35.2 20.3 11.39 36.6 8.6 11.52 32.4 27.2 11.62 34.0 19.7 11.85 35.3 8.3 11.99
26.7 34.2 29.7 11.22 35.9 25.5 11.42 37.3 16.4 11.55 33.0 30.6 11.65 34.7 24.6 11.88 36.0 15.8 12.02
29.4 35.4 32.8 11.25 36.6 30.8 11.45 38.0 23.2 11.58 33.7 33.0 11.68 35.4 29.7 11.91 36.7 22.4 12.05
32.2 36.6 34.9 11.28 37.4 34.6 11.48 38.8 29.0 11.61 34.3 34.3 11.71 36.1 33.4 11.94 37.5 28.0 12.08
3750
23.9 33.5 29.2 11.43 35.7 22.3 11.76 37.1 9.6 11.76 32.8 30.1 11.86 34.5 21.6 11.98 35.8 9.3 12.23
26.7 34.7 33.0 11.46 36.4 28.0 11.66 37.8 18.1 11.79 33.5 33.5 11.89 35.0 27.1 12.00 36.5 17.5 12.26
29.4 35.9 34.9 11.49 37.1 34.1 11.69 38.6 25.5 11.82 34.2 34.2 11.92 35.9 32.9 12.15 37.2 24.7 12.29
32.2 37.2 36.4 11.52 37.9 34.4 11.72 39.3 32.0 11.85 34.9 34.9 11.95 36.6 33.3 12.18 38.0 30.9 12.32
4000
23.9 34.0 30.1 11.74 36.2 21.7 11.94 37.5 9.2 12.07 33.6 29.8 12.17 35.0 21.0 12.40 36.3 8.9 12.54
26.7 35.2 33.8 11.77 36.9 27.1 11.97 38.3 17.4 12.10 34.3 33.0 12.20 35.7 26.3 12.43 37.0 16.8 12.57
29.4 36.4 35.4 11.80 37.6 32.7 12.00 39.1 24.7 12.13 35.0 35.0 12.23 36.4 31.7 12.46 37.7 23.9 12.60
32.2 37.7 37.0 11.83 38.4 36.9 12.03 39.8 30.9 12.16 35.7 35.7 12.26 37.1 35.7 12.49 38.5 29.8 12.63
