Outdoor main PCB ports instructions
Discharge temperature detection port of inverter compressor A
DC 0~5V (in dynamic change)
Discharge temperature detection port of inverter compressor A or B
DC 0~5V (in dynamic change)
Temperature detection port of inverter module
DC 0~5V (in dynamic change)
Wiring port for communication between indoor and outdoor units, indoor unit
network, outdoor unit network and network accounting
Three-phase detection port
Power input of No.1 transformer
Power input of No.2 transformer
Heat output of inverter compressor A electrical heater
Heat output of inverter compressor B electrical heater
The first pin on left: DC 12V
The other four pins: in dynamic change
Four-way valve output port
One-way valve output port
Power output of No.1 transformer
The voltage between upper tow pins: AC
13.5V;  The  voltage  between  under  tow
pins: AC 9V
Power output of No.2 transformer
The voltage between upper tow pins: AC
14.5V;  The  voltage  between  under  tow
pins: AC 14.5V
Activation port of inverter module B
The third pin on the left: DC3.3V
Voltage detection port of inverter module B
Voltage detection port of inverter module A
Activation port of inverter module A
The third pin on the left: DC3.3V
Power supply port of main PCB
ON/OFF signal input port for system low pressure detection
ON/OFF signal input port for system high pressure detection
Current detection port of inverter compressor A and B
AC 0~7.8V (in dynamic change)
Input port for system high pressure detection
DC 0~5V (in dynamic change)
Outdoor ambient temperature and condenser temperature detection port
DC 0~5V (in dynamic change)
Outdoor units communication port
The first pin on left: DC 12V
The other four pins: in dynamic change
