Midea MV6-i280WV2GN1-E

V6-i VRF 50/60Hz
57
Part 5
- Electrical Components and Wiring Diagrams
20-32HP
Figure 5-1.3: 20-32HP top layer of electric control box
Figure 5-1.4: 20-32HP bottom layer of electric control box
Power supply
terminals
Communication
terminals block
Inductor
Inductor
Filter board
Main PCB
Inverter
module
Inverter
module
Reactor Reactor
Fan module
Fan module
Pipe temp. sensor
Compressor
connection wiring
Compressor
connection wiring
Pipe temp. sensor
Bridge rectifier
Bridge rectifier
