Midea MV8M-120WV2RN1 - Page 39

V8 Mini R410A VRF 50Hz
37
Part 2
-
Outdoor Unit Engineering Data
Table2-8.2:140 model cooling capacity(continued)
CR
Outdoor air
temp.
(°CDB)
Indoor air temp. (°C DB/WD)
22/15
23.3/16
25.8/18
27/19
28.2/20
30.7/22
32/24
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
50%
-15
4.8
0.5
5.4
0.5
6.5
0.6
7.0
0.7
7.5
0.8
8.6
0.9
9.7
1.0
-12
4.8
0.5
5.4
0.5
6.5
0.6
7.0
0.7
7.5
0.8
8.6
0.9
9.7
1.0
-10
4.8
0.5
5.4
0.5
6.5
0.6
7.0
0.7
7.5
0.8
8.6
0.9
9.7
1.0
-8
4.8
0.5
5.4
0.5
6.5
0.7
7.0
0.7
7.5
0.8
8.6
0.9
9.7
1.0
-5
4.8
0.5
5.4
0.6
6.5
0.7
7.0
0.7
7.5
0.8
8.6
0.9
9.7
1.0
-2
4.8
0.5
5.4
0.6
6.5
0.7
7.0
0.7
7.5
0.8
8.6
0.9
9.7
1.0
0
4.8
0.5
5.4
0.6
6.5
0.7
7.0
0.7
7.5
0.8
8.6
0.9
9.7
1.1
2
4.8
0.5
5.4
0.6
6.5
0.7
7.0
0.7
7.5
0.8
8.6
0.9
9.7
1.2
4
4.8
0.5
5.4
0.6
6.5
0.7
7.0
0.8
7.5
0.8
8.6
1.0
9.7
1.3
6
4.8
0.5
5.4
0.6
6.5
0.7
7.0
0.8
7.5
0.9
8.6
1.0
9.7
1.4
8
4.8
0.6
5.4
0.6
6.5
0.7
7.0
0.8
7.5
0.9
8.6
1.1
9.7
1.4
10
4.8
0.6
5.4
0.6
6.5
0.8
7.0
0.9
7.5
1.0
8.6
1.1
9.7
1.4
12
4.8
0.6
5.4
0.6
6.5
0.8
7.0
0.9
7.5
1.0
8.6
1.1
9.7
1.4
14
4.8
0.6
5.4
0.6
6.5
0.8
7.0
0.9
7.5
1.0
8.6
1.1
9.7
1.4
16
4.8
0.6
5.4
0.7
6.5
0.8
7.0
0.9
7.5
1.0
8.6
1.2
9.7
1.5
18
4.8
0.7
5.4
0.7
6.5
0.8
7.0
0.9
7.5
1.0
8.6
1.2
9.7
1.5
20
4.8
0.7
5.4
0.8
6.5
0.9
7.0
1.0
7.5
1.1
8.6
1.3
9.7
1.7
21
4.8
0.8
5.4
0.8
6.5
1.0
7.0
1.1
7.5
1.2
8.6
1.4
9.7
1.7
23
4.8
0.8
5.4
0.9
6.5
1.1
7.0
1.2
7.5
1.3
8.6
1.5
9.7
1.9
25
4.8
0.9
5.4
1.0
6.5
1.2
7.0
1.3
7.5
1.4
8.6
1.7
9.7
2.1
27
4.8
1.0
5.4
1.1
6.5
1.3
7.0
1.4
7.5
1.5
8.6
1.8
9.7
2.2
29
4.8
1.1
5.4
1.2
6.5
1.4
7.0
1.5
7.5
1.7
8.6
2.0
9.7
2.4
31
4.8
1.2
5.4
1.3
6.5
1.5
7.0
1.7
7.5
1.8
8.6
2.1
9.7
2.6
33
4.8
1.3
5.4
1.4
6.5
1.6
7.0
1.8
7.5
1.9
8.6
2.3
9.7
2.8
35
4.8
1.3
5.4
1.5
6.5
1.8
7.0
1.9
7.5
2.1
8.6
2.5
9.7
3.0
37
4.8
1.4
5.4
1.6
6.5
1.9
7.0
2.1
7.5
2.3
8.6
2.7
9.7
3.2
39
4.8
1.5
5.4
1.7
6.5
2.0
7.0
2.2
7.5
2.4
8.6
2.9
9.7
3.5
41
4.8
1.7
5.4
1.8
6.5
2.2
7.0
2.4
7.5
2.6
8.6
3.1
9.7
3.8
43
4.8
1.8
5.4
2.0
6.5
2.4
7.0
2.6
7.5
2.8
8.6
3.3
9.7
4.0
45
4.8
1.9
5.4
2.1
6.5
2.5
7.0
2.8
7.5
3.1
8.6
3.6
9.7
4.4
48
4.8
2.1
5.4
2.4
6.5
2.9
7.0
3.1
7.5
3.4
8.6
4.0
9.0
4.3
50
4.8
2.3
5.4
2.5
6.5
3.1
7.0
3.4
7.3
3.6
7.9
3.8
8.2
3.9
52
4.8
2.5
5.4
2.8
5.9
3.0
6.2
3.1
6.5
3.2
7.1
3.3
7.2
3.3
Abbreviations:
CR: Combination ratio
TC: Total capacity (kW)
PI: Power input (compressor + outdoor fan motor) (kW)
Notes:
Shaded cells indicate rating condition.
