Midea V8 Mini Series Engineering Data Book
140-160 model
Table 2-1.2: 140-160 model specifications
Model
140
160
Model name
MV8M-140WV2N1
MV8M-160WV2N1
Power supply
220-240V, ~, 50Hz
Cooling
1
Capacity
kW
14.0
15.5
kBtu/h
47
52
Power input
kW
5.19
5.96
EER
2.70
2.60
Heating
2
(Rated)
Capacity
kW
14.0
15.5
kBtu/h
47
52
Power input
kW
3.68
4.19
COP
3.80
3.70
Heating2(Max)
Capacity
kW
16.0
17.5
kBtu/h
54
59
Power input
kW
4.71
5.30
COP
3.40
3.30
SEER
7.00
6.80
ηs,c
277.0%
269.0%
SCOP
4.80
4.80
ηs,h
189.0%
189.0%
Connected indoor unit
Total capacity
50%-160%
5
Maximum quantity
10
11
Compressor
Type
DC
Quantity
1
Oil type
RB75EA
Start-up method
Soft start
Fan
Type
Propeller
Motor type
DC
Quantity
1
Motor output
kW
0.2
Static pressure
Pa
0-35
Airflow rate
m
3
/h
5000
5000
Drive type
Direct
Refrigerant
Type
R410A
Factory charge
kg
4.1
4.1
Pipe connections
3
Liquid pipe
mm
Φ9.52
Φ9.52
Gas pipe
mm
Φ15.9
Φ15.9
Sound pressure level
4
dB(A)
56
56
Sound power level
4
dB(A)
73
74
Net dimensions (W×H×D)
mm
1073x864x523
Packed dimensions (W×H×D)
mm
1120x980x560
Net weight
kg
94
94
Gross weight
kg
104
104
Ambient temp.
Cooling
o
C
-15℃～52℃
6
operation range
Heating
o
C
-20~16.5
o
C (WB)/-20~30
o
C (DB)
Notes:
1. Indoor air temperature 27°C DB, 19°C WB; outdoor air temperature 35°C DB; equivalent refrigerant piping length 5m with zero level difference.
2. Indoor air temperature 20°C DB; outdoor air temperature 7°C DB, 6°C WB; equivalent refrigerant piping length 5m with zero level difference.
3. Diameters given are those of the unit's stop valve. Refer to Part 3, “3 Refrigerant Piping Design” for installation dimensions of refrigerant pipe.
4. Sound pressure level is measured at a position 1m in front of the unit and 1.3m above the floor in a semi-anechoic chamber.
5. If there are non V8 series indoor units in system the total combination ratio must not exceed 130%
6. Outdoor operating temperature under -5 °C in "cooling" mode, the startup capacity of IDUs must meet at least 30% of ODU capacity
