Series Engineering Data Book
8 Capacity Tables
8.1 Cooling Capacity Tables
Table2-8.1:80 model cooling capacity
CR
Outdoor air
temp.
(°CDB)
Indoor air temp. (°C DB/WD)
22/15
23.3/16
25.8/18
27/19
28.2/20
30.7/22
32/24
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
130%
-15
6.5
0.9
7.2
1.0
8.6
1.2
9.4
1.2
10.1
1.3
11.5
1.6
13.0
1.8
-12
6.5
0.9
7.2
1.0
8.6
1.2
9.4
1.2
10.1
1.3
11.5
1.6
13.0
1.9
-10
6.5
0.9
7.2
1.0
8.6
1.2
9.4
1.3
10.1
1.3
11.5
1.6
13.0
1.9
-8
6.5
0.9
7.2
1.0
8.6
1.2
9.4
1.3
10.1
1.3
11.5
1.6
13.0
1.9
-5
6.5
1.0
7.2
1.0
8.6
1.2
9.4
1.3
10.1
1.4
11.5
1.6
13.0
1.9
-2
6.5
1.0
7.2
1.1
8.6
1.2
9.4
1.3
10.1
1.4
11.5
1.6
13.0
1.9
0
6.5
1.0
7.2
1.1
8.6
1.2
9.4
1.3
10.1
1.4
11.5
1.7
13.0
2.0
2
6.5
1.0
7.2
1.1
8.6
1.2
9.4
1.3
10.1
1.4
11.5
1.7
13.0
2.0
4
6.5
1.0
7.2
1.1
8.6
1.3
9.4
1.4
10.1
1.4
11.5
1.7
13.0
2.0
6
6.5
1.1
7.2
1.1
8.6
1.3
9.4
1.4
10.1
1.5
11.5
1.7
13.0
2.0
8
6.5
1.1
7.2
1.2
8.6
1.3
9.4
1.4
10.1
1.5
11.5
1.7
13.0
2.1
10
6.5
1.2
7.2
1.2
8.6
1.4
9.4
1.5
10.1
1.5
11.5
1.8
13.0
2.2
12
6.5
1.2
7.2
1.3
8.6
1.4
9.4
1.5
10.1
1.5
11.5
1.8
13.0
2.3
14
6.5
1.2
7.2
1.3
8.6
1.5
9.4
1.5
10.1
1.7
11.5
1.9
13.0
2.5
16
6.5
1.2
7.2
1.4
8.6
1.5
9.4
1.6
10.1
1.7
11.5
2.1
12.6
2.6
18
6.5
1.3
7.2
1.4
8.6
1.5
9.4
1.6
10.1
1.8
11.5
2.3
12.4
2.7
20
6.5
1.3
7.2
1.4
8.6
1.6
9.4
1.8
10.1
2.0
11.5
2.5
12.3
2.9
21
6.5
1.3
7.2
1.5
8.6
1.7
9.4
1.9
10.1
2.1
11.5
2.6
12.2
3.0
23
6.5
1.4
7.2
1.5
8.6
1.8
9.4
2.0
10.1
2.3
11.5
2.8
12.1
3.1
25
6.5
1.4
7.2
1.6
8.6
2.0
9.4
2.2
10.1
2.5
11.5
3.1
11.9
3.2
27
6.5
1.5
7.2
1.7
8.6
2.2
9.4
2.4
10.1
2.7
11.5
3.3
11.7
3.4
29
6.5
1.7
7.2
1.9
8.6
2.3
9.4
2.6
10.1
2.9
11.5
3.6
11.6
3.5
31
6.5
1.8
7.2
2.0
8.6
2.5
9.4
2.8
10.1
3.1
11.1
3.6
11.4
3.7
33
6.5
1.9
7.2
2.2
8.6
2.7
9.4
3.0
10.1
3.4
11.0
3.8
11.2
3.8
35
6.5
2.1
7.2
2.3
8.6
2.9
9.4
3.3
10.1
3.6
10.8
4.0
11.1
4.0
37
6.5
2.2
7.2
2.5
8.6
3.1
9.4
3.5
10.1
3.9
10.6
4.1
10.9
4.2
39
6.5
2.4
7.2
2.7
8.6
3.4
9.4
3.8
10.1
4.2
10.5
4.3
10.7
4.3
41
6.5
2.6
7.2
2.9
8.6
3.6
9.4
4.1
9.8
4.4
10.3
4.5
10.5
4.5
43
6.5
2.8
7.2
3.1
8.6
3.9
9.4
4.4
9.6
4.5
10.0
4.5
10.3
4.6
45
6.5
2.9
7.2
3.3
8.6
4.2
8.9
4.4
9.2
4.5
9.6
4.5
9.7
4.3
48
6.5
3.3
7.0
3.6
7.6
3.8
7.7
3.7
7.8
3.6
8.1
3.5
8.1
3.4
50
5.9
3.1
6.2
3.2
6.6
3.3
6.6
3.1
6.7
3.1
6.8
2.9
6.9
2.9
52
5.0
2.7
5.3
2.8
5.5
2.7
5.5
2.6
5.5
2.6
5.8
2.5
5.6
2.3
120%
-15
6.0
0.8
6.6
0.9
8.0
1.1
8.6
1.1
9.3
1.2
10.6
1.4
12.0
1.6
-12
6.0
0.9
6.6
0.9
8.0
1.1
8.6
1.1
9.3
1.2
10.6
1.4
12.0
1.6
-10
6.0
0.9
6.6
0.9
8.0
1.1
8.6
1.2
9.3
1.2
10.6
1.4
12.0
1.7
-8
6.0
0.9
6.6
0.9
8.0
1.1
8.6
1.2
9.3
1.2
10.6
1.5
12.0
1.7
-5
6.0
0.9
6.6
1.0
8.0
1.1
8.6
1.2
9.3
1.2
10.6
1.5
12.0
1.7
-2
6.0
0.9
6.6
1.0
8.0
1.1
8.6
1.2
9.3
1.2
10.6
1.5
12.0
1.7
0
6.0
0.9
6.6
1.0
8.0
1.1
8.6
1.2
9.3
1.3
10.6
1.5
12.0
1.7
2
6.0
1.0
6.6
1.0
8.0
1.2
8.6
1.2
9.3
1.3
10.6
1.5
12.0
1.7
4
6.0
1.0
6.6
1.0
8.0
1.2
8.6
1.2
9.3
1.3
10.6
1.5
12.0
1.8
6
6.0
1.0
6.6
1.1
8.0
1.2
8.6
1.3
9.3
1.4
10.6
1.5
12.0
1.8
8
6.0
1.0
6.6
1.1
8.0
1.2
8.6
1.3
9.3
1.4
10.6
1.5
12.0
1.8
10
6.0
1.0
6.6
1.1
8.0
1.3
8.6
1.3
9.3
1.4
10.6
1.6
12.0
1.9
12
6.0
1.1
6.6
1.2
8.0
1.3
8.6
1.4
9.3
1.4
10.6
1.6
12.0
2.0
14
6.0
1.1
6.6
1.2
8.0
1.3
8.6
1.4
9.3
1.5
10.6
1.7
12.0
2.1
16
6.0
1.2
6.6
1.2
8.0
1.4
8.6
1.5
9.3
1.6
10.6
1.8
12.0
2.3
18
6.0
1.2
6.6
1.3
8.0
1.4
8.6
1.6
9.3
1.6
10.6
2.0
12.0
2.5
20
6.0
1.2
6.6
1.3
8.0
1.5
8.6
1.6
9.3
1.7
10.6
2.1
12.0
2.8
21
6.0
1.3
6.6
1.3
8.0
1.5
8.6
1.7
9.3
1.8
10.6
2.2
12.0
2.9
23
6.0
1.3
6.6
1.4
8.0
1.6
8.6
1.8
9.3
2.0
10.6
2.4
12.0
3.1
25
6.0
1.4
6.6
1.4
8.0
1.8
8.6
2.0
9.3
2.2
10.6
2.6
11.6
3.2
27
6.0
1.4
6.6
1.6
8.0
1.9
8.6
2.1
9.3
2.3
10.6
2.9
11.5
3.3
29
6.0
1.5
6.6
1.7
8.0
2.1
8.6
2.3
9.3
2.5
10.6
3.1
11.3
3.5
31
6.0
1.6
6.6
1.8
8.0
2.2
8.6
2.5
9.3
2.7
10.6
3.3
11.1
3.6
33
6.0
1.7
6.6
2.0
8.0
2.4
8.6
2.7
9.3
3.0
10.6
3.6
11.0
3.8
35
6.0
1.9
6.6
2.1
8.0
2.6
8.6
2.9
9.3
3.2
10.6
3.9
10.8
3.9
37
6.0
2.0
6.6
2.3
8.0
2.8
8.6
3.1
9.3
3.4
10.6
4.2
10.7
4.1
39
6.0
2.2
6.6
2.4
8.0
3.0
8.6
3.3
9.3
3.7
10.2
4.2
10.5
4.3
41
6.0
2.3
6.6
2.6
8.0
3.2
8.6
3.6
9.3
4.0
10.1
4.4
10.3
4.5
43
6.0
2.5
6.6
2.8
8.0
3.5
8.6
3.9
9.3
4.3
9.8
4.5
10.0
4.5
45
6.0
2.7
6.6
3.0
8.0
3.7
8.6
4.1
8.9
4.4
9.5
4.5
9.6
4.5
48
6.0
3.0
6.6
3.3
7.4
3.7
7.7
3.8
7.8
3.7
7.9
3.5
8.1
3.5
50
5.7
3.0
6.0
3.1
6.5
3.3
6.6
3.2
6.7
3.1
6.8
3.0
6.9
2.9
52
4.9
2.6
5.2
2.7
5.5
2.8
5.4
2.6
5.6
2.6
5.6
2.4
5.9
2.5
Abbreviations:
CR: Combination ratio; TC: Total capacity (kW); PI: Power input (compressor + outdoor fan motor) (kW) Notes: Shaded cells indicate rating condition.
