Part 2
-
Outdoor Unit Engineering Data
Table2-8.1:80 model cooling capacity(continued)
CR
Outdoor air
temp.
(°CDB)
Indoor air temp. (°C DB/WD)
22/15
23.3/16
25.8/18
27/19
28.2/20
30.7/22
32/24
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
110%
-15
5.5
0.8
6.1
0.8
7.3
1.0
7.9
1.0
8.5
1.1
9.7
1.3
11.0
1.5
-12
5.5
0.8
6.1
0.8
7.3
1.0
7.9
1.0
8.5
1.1
9.7
1.3
11.0
1.5
-10
5.5
0.8
6.1
0.9
7.3
1.0
7.9
1.0
8.5
1.1
9.7
1.3
11.0
1.5
-8
5.5
0.8
6.1
0.9
7.3
1.0
7.9
1.1
8.5
1.1
9.7
1.3
11.0
1.5
-5
5.5
0.8
6.1
0.9
7.3
1.0
7.9
1.1
8.5
1.1
9.7
1.3
11.0
1.5
-2
5.5
0.8
6.1
0.9
7.3
1.0
7.9
1.1
8.5
1.1
9.7
1.3
11.0
1.5
0
5.5
0.9
6.1
0.9
7.3
1.0
7.9
1.1
8.5
1.2
9.7
1.3
11.0
1.5
2
5.5
0.9
6.1
0.9
7.3
1.1
7.9
1.1
8.5
1.2
9.7
1.3
11.0
1.5
4
5.5
0.9
6.1
1.0
7.3
1.1
7.9
1.1
8.5
1.2
9.7
1.3
11.0
1.5
6
5.5
0.9
6.1
1.0
7.3
1.1
7.9
1.2
8.5
1.2
9.7
1.4
11.0
1.6
8
5.5
1.0
6.1
1.0
7.3
1.1
7.9
1.2
8.5
1.3
9.7
1.4
11.0
1.6
10
5.5
1.0
6.1
1.0
7.3
1.2
7.9
1.3
8.5
1.3
9.7
1.5
11.0
1.6
12
5.5
1.0
6.1
1.1
7.3
1.2
7.9
1.3
8.5
1.4
9.7
1.5
11.0
1.7
14
5.5
1.1
6.1
1.1
7.3
1.3
7.9
1.4
8.5
1.4
9.7
1.5
11.0
1.8
16
5.5
1.1
6.1
1.2
7.3
1.3
7.9
1.4
8.5
1.5
9.7
1.6
11.0
1.9
18
5.5
1.1
6.1
1.2
7.3
1.3
7.9
1.4
8.5
1.5
9.7
1.6
11.0
2.1
20
5.5
1.2
6.1
1.2
7.3
1.4
7.9
1.4
8.5
1.5
9.7
1.8
11.0
2.3
21
5.5
1.2
6.1
1.3
7.3
1.4
7.9
1.5
8.5
1.6
9.7
1.9
11.0
2.4
23
5.5
1.2
6.1
1.3
7.3
1.4
7.9
1.6
8.5
1.7
9.7
2.1
11.0
2.6
25
5.5
1.2
6.1
1.3
7.3
1.6
7.9
1.7
8.5
1.9
9.7
2.3
11.0
2.9
27
5.5
1.3
6.1
1.4
7.3
1.7
7.9
1.9
8.5
2.0
9.7
2.4
11.0
3.1
29
5.5
1.4
6.1
1.5
7.3
1.8
7.9
2.0
8.5
2.2
9.7
2.6
11.0
3.3
31
5.5
1.5
6.1
1.6
7.3
2.0
7.9
2.2
8.5
2.4
9.7
2.9
11.0
3.6
33
5.5
1.6
6.1
1.7
7.3
2.1
7.9
2.3
8.5
2.6
9.7
3.1
10.7
3.7
35
5.5
1.7
6.1
1.9
7.3
2.3
7.9
2.5
8.5
2.8
9.7
3.3
10.6
3.9
37
5.5
1.8
6.1
2.0
7.3
2.5
7.9
2.7
8.5
3.0
9.7
3.6
10.4
4.1
39
5.5
1.9
6.1
2.2
7.3
2.6
7.9
2.9
8.5
3.2
9.7
3.9
10.2
4.2
41
5.5
2.1
6.1
2.3
7.3
2.8
7.9
3.1
8.5
3.5
9.7
4.2
10.1
4.4
43
5.5
2.2
6.1
2.5
7.3
3.1
7.9
3.4
8.5
3.7
9.7
4.5
9.8
4.5
45
5.5
2.4
6.1
2.7
7.3
3.3
7.9
3.6
8.5
4.0
9.3
4.5
9.5
4.5
48
5.5
2.7
6.1
3.0
7.3
3.7
7.4
3.7
7.7
3.8
7.9
3.6
8.0
3.5
50
5.5
2.9
5.8
3.0
6.5
3.3
6.5
3.2
6.7
3.2
6.8
3.0
6.9
3.0
52
4.6
2.5
5.0
2.7
5.3
2.7
5.4
2.6
5.6
2.6
5.6
2.5
5.7
2.4
100%
-15
5.0
0.7
5.5
0.8
6.6
0.9
7.2
0.9
7.8
1.0
8.9
1.1
10.0
1.3
-12
5.0
0.7
5.5
0.8
6.6
0.9
7.2
0.9
7.8
1.0
8.9
1.1
10.0
1.3
-10
5.0
0.7
5.5
0.8
6.6
0.9
7.2
0.9
7.8
1.0
8.9
1.1
10.0
1.3
-8
5.0
0.7
5.5
0.8
6.6
0.9
7.2
1.0
7.8
1.0
8.9
1.2
10.0
1.3
-5
5.0
0.7
5.5
0.8
6.6
0.9
7.2
1.0
7.8
1.0
8.9
1.2
10.0
1.3
-2
5.0
0.8
5.5
0.8
6.6
0.9
7.2
1.0
7.8
1.0
8.9
1.2
10.0
1.4
0
5.0
0.8
5.5
0.8
6.6
1.0
7.2
1.0
7.8
1.1
8.9
1.2
10.0
1.4
2
5.0
0.8
5.5
0.9
6.6
1.0
7.2
1.0
7.8
1.1
8.9
1.2
10.0
1.4
4
5.0
0.8
5.5
0.9
6.6
1.0
7.2
1.0
7.8
1.1
8.9
1.2
10.0
1.4
6
5.0
0.9
5.5
0.9
6.6
1.0
7.2
1.1
7.8
1.1
8.9
1.2
10.0
1.4
8
5.0
0.9
5.5
0.9
6.6
1.1
7.2
1.1
7.8
1.2
8.9
1.3
10.0
1.4
10
5.0
0.9
5.5
0.9
6.6
1.1
7.2
1.1
7.8
1.2
8.9
1.3
10.0
1.5
12
5.0
0.9
5.5
1.0
6.6
1.1
7.2
1.2
7.8
1.2
8.9
1.4
10.0
1.5
14
5.0
0.9
5.5
1.0
6.6
1.1
7.2
1.2
7.8
1.3
8.9
1.4
10.0
1.6
16
5.0
1.0
5.5
1.0
6.6
1.2
7.2
1.3
7.8
1.3
8.9
1.5
10.0
1.6
18
5.0
1.0
5.5
1.1
6.6
1.2
7.2
1.3
7.8
1.4
8.9
1.5
10.0
1.8
20
5.0
1.1
5.5
1.1
6.6
1.3
7.2
1.3
7.8
1.4
8.9
1.6
10.0
1.9
21
5.0
1.1
5.5
1.2
6.6
1.3
7.2
1.4
7.8
1.4
8.9
1.6
10.0
2.0
23
5.0
1.1
5.5
1.2
6.6
1.4
7.2
1.4
7.8
1.5
8.9
1.8
10.0
2.2
25
5.0
1.2
5.5
1.2
6.6
1.4
7.2
1.5
7.8
1.6
8.9
1.9
10.0
2.4
27
5.0
1.2
5.5
1.3
6.6
1.5
7.2
1.6
7.8
1.8
8.9
2.1
10.0
2.6
29
5.0
1.2
5.5
1.3
6.6
1.6
7.2
1.8
7.8
1.9
8.9
2.3
10.0
2.8
31
5.0
1.3
5.5
1.4
6.6
1.7
7.2
1.9
7.8
2.1
8.9
2.4
10.0
3.0
33
5.0
1.4
5.5
1.6
6.6
1.9
7.2
2.1
7.8
2.2
8.9
2.6
10.0
3.3
35
5.0
1.5
5.5
1.7
6.6
2.0
7.2
2.2
7.8
2.4
8.9
2.9
10.0
3.5
37
5.0
1.6
5.5
1.8
6.6
2.2
7.2
2.4
7.8
2.6
8.9
3.1
10.0
3.8
39
5.0
1.7
5.5
1.9
6.6
2.3
7.2
2.6
7.8
2.8
8.9
3.3
10.0
4.1
41
5.0
1.9
5.5
2.1
6.6
2.5
7.2
2.7
7.8
3.0
8.9
3.6
10.0
4.4
43
5.0
2.0
5.5
2.2
6.6
2.7
7.2
3.0
7.8
3.2
8.9
3.8
9.6
4.4
45
5.0
2.2
5.5
2.4
6.6
2.9
7.2
3.2
7.8
3.5
8.9
4.1
9.2
4.4
48
5.0
2.4
5.5
2.7
6.6
3.2
7.2
3.5
7.4
3.7
7.8
3.7
7.9
3.6
50
5.0
2.6
5.5
2.9
6.2
3.2
6.5
3.3
6.6
3.2
6.7
3.1
6.8
3.0
52
4.5
2.4
4.8
2.6
5.3
2.7
5.4
2.7
5.5
2.6
5.6
2.5
5.7
2.5
Abbreviations:
CR: Combination ratio
TC: Total capacity (kW)
PI: Power input (compressor + outdoor fan motor) (kW)
Notes:
Shaded cells indicate rating condition.
Table continued on next page …
