V8 Mini R410A VRF 50Hz
27
Part 2 - Outdoor Unit Engineering Data
Legend
Code
Name
Code
Name
COMP
Compressor
T3
Main heat exchanger pipe temperature sensor
FAN
DC fan
T4
Outdoor ambient temperature sensor
H-PRO
High pressure switch
T5
Liquid pipe temperature sensor
HEAT A
Crankcase heater
T6B
Plate heat exchanger outlet temperature sensor
Pc
High pressure sensor
T71
Suction temperature sensor
Pe
Low pressure sensor
T7C1
Compressor discharge temperature sensor
ST1
Four-way valve
T8
Heat exchanger gas temperature sensor
XT1
Terminal block
TL
Heat exchanger liquid temperature sensor
EEVA/C
Electronic expansion valve
