Part 2
-
Outdoor Unit Engineering Data
Table2-8.1:80 model cooling capacity(continued)
CR
Outdoor air
temp.
(°CDB)
Indoor air temp. (°C DB/WD)
22/15
23.3/16
25.8/18
27/19
28.2/20
30.7/22
32/24
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
70%
-15
3.5
0.5
3.9
0.6
4.7
0.6
5.0
0.6
5.4
0.7
6.2
0.8
7.0
0.9
-12
3.5
0.5
3.9
0.6
4.7
0.6
5.0
0.7
5.4
0.7
6.2
0.8
7.0
0.9
-10
3.5
0.6
3.9
0.6
4.7
0.6
5.0
0.7
5.4
0.7
6.2
0.8
7.0
0.9
-8
3.5
0.6
3.9
0.6
4.7
0.6
5.0
0.7
5.4
0.7
6.2
0.8
7.0
0.9
-5
3.5
0.6
3.9
0.6
4.7
0.6
5.0
0.7
5.4
0.7
6.2
0.8
7.0
0.9
-2
3.5
0.6
3.9
0.6
4.7
0.7
5.0
0.7
5.4
0.7
6.2
0.8
7.0
0.9
0
3.5
0.6
3.9
0.7
4.7
0.7
5.0
0.8
5.4
0.8
6.2
0.9
7.0
0.9
2
3.5
0.7
3.9
0.7
4.7
0.7
5.0
0.8
5.4
0.8
6.2
0.9
7.0
0.9
4
3.5
0.7
3.9
0.7
4.7
0.8
5.0
0.8
5.4
0.8
6.2
0.9
7.0
1.0
6
3.5
0.7
3.9
0.7
4.7
0.8
5.0
0.8
5.4
0.8
6.2
0.9
7.0
1.0
8
3.5
0.7
3.9
0.7
4.7
0.8
5.0
0.8
5.4
0.8
6.2
1.0
7.0
1.0
10
3.5
0.7
3.9
0.7
4.7
0.8
5.0
0.9
5.4
0.9
6.2
1.0
7.0
1.1
12
3.5
0.7
3.9
0.8
4.7
0.8
5.0
0.9
5.4
0.9
6.2
1.0
7.0
1.1
14
3.5
0.8
3.9
0.8
4.7
0.9
5.0
0.9
5.4
0.9
6.2
1.0
7.0
1.1
16
3.5
0.8
3.9
0.8
4.7
0.9
5.0
0.9
5.4
1.0
6.2
1.1
7.0
1.2
18
3.5
0.8
3.9
0.9
4.7
0.9
5.0
0.9
5.4
1.0
6.2
1.1
7.0
1.2
20
3.5
0.8
3.9
0.9
4.7
0.9
5.0
1.0
5.4
1.0
6.2
1.1
7.0
1.2
21
3.5
0.9
3.9
0.9
4.7
1.0
5.0
1.0
5.4
1.1
6.2
1.2
7.0
1.3
23
3.5
0.9
3.9
0.9
4.7
1.0
5.0
1.0
5.4
1.1
6.2
1.2
7.0
1.3
25
3.5
0.9
3.9
0.9
4.7
1.0
5.0
1.1
5.4
1.1
6.2
1.2
7.0
1.4
27
3.5
0.9
3.9
1.0
4.7
1.0
5.0
1.1
5.4
1.1
6.2
1.3
7.0
1.5
29
3.5
0.9
3.9
1.0
4.7
1.1
5.0
1.1
5.4
1.2
6.2
1.4
7.0
1.6
31
3.5
0.9
3.9
1.0
4.7
1.1
5.0
1.2
5.4
1.3
6.2
1.5
7.0
1.8
33
3.5
1.0
3.9
1.1
4.7
1.2
5.0
1.3
5.4
1.4
6.2
1.6
7.0
1.9
35
3.5
1.1
3.9
1.1
4.7
1.3
5.0
1.4
5.4
1.5
6.2
1.7
7.0
2.1
37
3.5
1.1
3.9
1.2
4.7
1.4
5.0
1.5
5.4
1.6
6.2
1.9
7.0
2.2
39
3.5
1.2
3.9
1.3
4.7
1.5
5.0
1.6
5.4
1.8
6.2
2.0
7.0
2.4
41
3.5
1.3
3.9
1.4
4.7
1.6
5.0
1.8
5.4
1.9
6.2
2.2
7.0
2.6
43
3.5
1.4
3.9
1.5
4.7
1.8
5.0
1.9
5.4
2.1
6.2
2.4
7.0
2.8
45
3.5
1.5
3.9
1.6
4.7
1.9
5.0
2.1
5.4
2.2
6.2
2.5
7.0
3.0
48
3.5
1.6
3.9
1.8
4.7
2.1
5.0
2.3
5.4
2.5
6.2
2.8
7.0
3.3
50
3.5
1.8
3.9
1.9
4.7
2.3
5.0
2.5
5.4
2.7
6.2
3.0
6.5
3.2
52
3.5
1.9
3.9
2.1
4.7
2.5
4.8
2.5
5.1
2.6
5.4
2.6
5.4
2.6
60%
-15
3.0
0.5
3.3
0.5
4.0
0.6
4.3
0.6
4.7
0.6
5.3
0.7
6.0
0.7
-12
3.0
0.5
3.3
0.5
4.0
0.6
4.3
0.6
4.7
0.6
5.3
0.7
6.0
0.7
-10
3.0
0.5
3.3
0.5
4.0
0.6
4.3
0.6
4.7
0.6
5.3
0.7
6.0
0.7
-8
3.0
0.5
3.3
0.5
4.0
0.6
4.3
0.6
4.7
0.6
5.3
0.7
6.0
0.8
-5
3.0
0.5
3.3
0.6
4.0
0.6
4.3
0.6
4.7
0.6
5.3
0.7
6.0
0.8
-2
3.0
0.6
3.3
0.6
4.0
0.6
4.3
0.7
4.7
0.7
5.3
0.7
6.0
0.8
0
3.0
0.6
3.3
0.6
4.0
0.7
4.3
0.7
4.7
0.7
5.3
0.8
6.0
0.8
2
3.0
0.6
3.3
0.6
4.0
0.7
4.3
0.7
4.7
0.7
5.3
0.8
6.0
0.8
4
3.0
0.6
3.3
0.6
4.0
0.7
4.3
0.7
4.7
0.8
5.3
0.8
6.0
0.9
6
3.0
0.6
3.3
0.7
4.0
0.7
4.3
0.7
4.7
0.8
5.3
0.8
6.0
0.9
8
3.0
0.6
3.3
0.7
4.0
0.7
4.3
0.7
4.7
0.8
5.3
0.8
6.0
0.9
10
3.0
0.6
3.3
0.7
4.0
0.7
4.3
0.7
4.7
0.8
5.3
0.9
6.0
0.9
12
3.0
0.7
3.3
0.7
4.0
0.8
4.3
0.8
4.7
0.8
5.3
0.9
6.0
0.9
14
3.0
0.7
3.3
0.7
4.0
0.8
4.3
0.8
4.7
0.8
5.3
0.9
6.0
1.0
16
3.0
0.7
3.3
0.7
4.0
0.8
4.3
0.8
4.7
0.8
5.3
0.9
6.0
1.0
18
3.0
0.7
3.3
0.8
4.0
0.8
4.3
0.9
4.7
0.9
5.3
0.9
6.0
1.0
20
3.0
0.7
3.3
0.8
4.0
0.8
4.3
0.9
4.7
0.9
5.3
1.0
6.0
1.0
21
3.0
0.8
3.3
0.8
4.0
0.9
4.3
0.9
4.7
0.9
5.3
1.0
6.0
1.1
23
3.0
0.8
3.3
0.8
4.0
0.9
4.3
0.9
4.7
1.0
5.3
1.0
6.0
1.1
25
3.0
0.8
3.3
0.8
4.0
0.9
4.3
0.9
4.7
1.0
5.3
1.0
6.0
1.1
27
3.0
0.8
3.3
0.8
4.0
0.9
4.3
1.0
4.7
1.0
5.3
1.1
6.0
1.2
29
3.0
0.9
3.3
0.9
4.0
0.9
4.3
1.0
4.7
1.0
5.3
1.1
6.0
1.3
31
3.0
0.9
3.3
0.9
4.0
1.0
4.3
1.0
4.7
1.1
5.3
1.2
6.0
1.4
33
3.0
0.9
3.3
1.0
4.0
1.0
4.3
1.1
4.7
1.2
5.3
1.3
6.0
1.6
35
3.0
1.0
3.3
1.0
4.0
1.1
4.3
1.2
4.7
1.3
5.3
1.4
6.0
1.7
37
3.0
1.0
3.3
1.1
4.0
1.2
4.3
1.3
4.7
1.4
5.3
1.6
6.0
1.8
39
3.0
1.1
3.3
1.2
4.0
1.3
4.3
1.4
4.7
1.5
5.3
1.7
6.0
2.0
41
3.0
1.2
3.3
1.2
4.0
1.4
4.3
1.5
4.7
1.6
5.3
1.8
6.0
2.1
43
3.0
1.2
3.3
1.3
4.0
1.5
4.3
1.6
4.7
1.7
5.3
2.0
6.0
2.3
45
3.0
1.3
3.3
1.4
4.0
1.6
4.3
1.7
4.7
1.9
5.3
2.1
6.0
2.5
48
3.0
1.5
3.3
1.5
4.0
1.8
4.3
1.9
4.7
2.1
5.3
2.4
6.0
2.7
50
3.0
1.6
3.3
1.7
4.0
1.9
4.3
2.1
4.7
2.2
5.3
2.5
6.0
3.0
52
3.0
1.7
3.3
1.8
4.0
2.1
4.3
2.3
4.7
2.4
5.1
2.6
5.3
2.7
Abbreviations:
CR: Combination ratio
TC: Total capacity (kW)
PI: Power input (compressor + outdoor fan motor) (kW)
Notes:
Shaded cells indicate rating condition.
Table continued on next page …
