V8 Mini R410A VRF 50Hz
43
Part 2
-
Outdoor Unit Engineering Data
Table2-8.3:120 model cooling capacity(continued)
CR
Outdoor air
temp.
(°CDB)
Indoor air temp. (°C DB/WD)
22/15
23.3/16
25.8/18
27/19
28.2/20
30.7/22
32/24
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
KW
70%
-15
6.0
0.6
6.6
0.7
7.9
0.8
8.6
0.8
9.3
0.9
10.6
1.1
11.9
1.3
-12
6.0
0.6
6.6
0.7
7.9
0.8
8.6
0.9
9.3
0.9
10.6
1.1
11.9
1.3
-10
6.0
0.6
6.6
0.7
7.9
0.8
8.6
0.9
9.3
0.9
10.6
1.1
11.9
1.3
-8
6.0
0.6
6.6
0.7
7.9
0.8
8.6
0.9
9.3
1.0
10.6
1.1
11.9
1.3
-5
6.0
0.6
6.6
0.7
7.9
0.8
8.6
0.9
9.3
1.0
10.6
1.1
11.9
1.3
-2
6.0
0.6
6.6
0.7
7.9
0.8
8.6
0.9
9.3
1.0
10.6
1.1
11.9
1.5
0
6.0
0.6
6.6
0.7
7.9
0.8
8.6
0.9
9.3
1.0
10.6
1.2
11.9
1.5
2
6.0
0.6
6.6
0.7
7.9
0.8
8.6
0.9
9.3
1.0
10.6
1.3
11.9
1.5
4
6.0
0.6
6.6
0.7
7.9
0.9
8.6
0.9
9.3
1.0
10.6
1.3
11.9
1.6
6
6.0
0.6
6.6
0.7
7.9
0.9
8.6
1.0
9.3
1.0
10.6
1.3
11.9
1.6
8
6.0
0.6
6.6
0.7
7.9
0.9
8.6
1.0
9.3
1.1
10.6
1.3
11.9
1.6
10
6.0
0.7
6.6
0.7
7.9
1.0
8.6
1.0
9.3
1.1
10.6
1.3
11.9
1.6
12
6.0
0.7
6.6
0.8
7.9
1.0
8.6
1.0
9.3
1.1
10.6
1.4
11.9
1.7
14
6.0
0.7
6.6
0.8
7.9
1.0
8.6
1.1
9.3
1.1
10.6
1.4
11.9
1.7
16
6.0
0.7
6.6
0.8
7.9
1.0
8.6
1.1
9.3
1.2
10.6
1.4
11.9
1.8
18
6.0
0.7
6.6
0.8
7.9
1.0
8.6
1.1
9.3
1.2
10.6
1.5
11.9
2.0
20
6.0
0.8
6.6
0.9
7.9
1.1
8.6
1.2
9.3
1.4
10.6
1.7
11.9
2.1
21
6.0
0.9
6.6
1.0
7.9
1.2
8.6
1.3
9.3
1.4
10.6
1.8
11.9
2.2
23
6.0
1.0
6.6
1.1
7.9
1.3
8.6
1.4
9.3
1.6
10.6
1.9
11.9
2.4
25
6.0
1.1
6.6
1.2
7.9
1.4
8.6
1.6
9.3
1.8
10.6
2.1
11.9
2.6
27
6.0
1.2
6.6
1.3
7.9
1.6
8.6
1.7
9.3
1.9
10.6
2.3
11.9
2.9
29
6.0
1.3
6.6
1.4
7.9
1.7
8.6
1.9
9.3
2.1
10.6
2.5
11.9
3.1
31
6.0
1.4
6.6
1.5
7.9
1.8
8.6
2.0
9.3
2.2
10.6
2.7
11.9
3.3
33
6.0
1.5
6.6
1.6
7.9
2.0
8.6
2.2
9.3
2.4
10.6
2.9
11.9
3.6
35
6.0
1.6
6.6
1.8
7.9
2.1
8.6
2.4
9.3
2.6
10.6
3.1
11.9
3.8
37
6.0
1.7
6.6
1.9
7.9
2.3
8.6
2.6
9.3
2.8
10.6
3.3
11.9
4.1
39
6.0
1.8
6.6
2.0
7.9
2.5
8.6
2.8
9.3
3.0
10.6
3.6
11.9
4.4
41
6.0
2.0
6.6
2.2
7.9
2.7
8.6
3.0
9.3
3.3
10.6
3.9
11.9
4.8
43
6.0
2.1
6.6
2.3
7.9
2.9
8.6
3.2
9.3
3.5
10.6
4.2
11.9
5.1
45
6.0
2.3
6.6
2.5
7.9
3.1
8.6
3.4
9.3
3.8
10.6
4.5
11.5
5.2
48
6.0
2.5
6.6
2.8
7.9
3.5
8.6
3.9
9.3
4.3
9.9
4.5
10.2
4.6
50
6.0
2.8
6.6
3.1
7.7
3.7
8.1
3.8
8.4
3.9
8.7
3.8
8.8
3.7
52
5.7
2.9
6.1
3.0
6.9
3.3
7.1
3.3
7.2
3.2
7.4
3.1
7.5
3.0
60%
-15
5.1
0.5
5.7
0.5
6.8
0.7
7.4
0.7
7.9
0.8
9.1
0.9
10.2
1.0
-12
5.1
0.5
5.7
0.5
6.8
0.7
7.4
0.7
7.9
0.8
9.1
0.9
10.2
1.0
-10
5.1
0.5
5.7
0.6
6.8
0.7
7.4
0.7
7.9
0.8
9.1
0.9
10.2
1.1
-8
5.1
0.5
5.7
0.6
6.8
0.7
7.4
0.7
7.9
0.8
9.1
0.9
10.2
1.1
-5
5.1
0.5
5.7
0.6
6.8
0.7
7.4
0.7
7.9
0.8
9.1
0.9
10.2
1.1
-2
5.1
0.5
5.7
0.6
6.8
0.7
7.4
0.8
7.9
0.8
9.1
0.9
10.2
1.1
0
5.1
0.5
5.7
0.6
6.8
0.7
7.4
0.8
7.9
0.8
9.1
1.0
10.2
1.1
2
5.1
0.5
5.7
0.6
6.8
0.7
7.4
0.8
7.9
0.8
9.1
1.0
10.2
1.2
4
5.1
0.5
5.7
0.6
6.8
0.7
7.4
0.8
7.9
0.8
9.1
1.0
10.2
1.2
6
5.1
0.6
5.7
0.6
6.8
0.7
7.4
0.8
7.9
0.9
9.1
1.1
10.2
1.3
8
5.1
0.6
5.7
0.6
6.8
0.8
7.4
0.8
7.9
0.9
9.1
1.1
10.2
1.3
10
5.1
0.6
5.7
0.6
6.8
0.8
7.4
0.9
7.9
0.9
9.1
1.1
10.2
1.3
12
5.1
0.6
5.7
0.6
6.8
0.8
7.4
0.9
7.9
1.0
9.1
1.1
10.2
1.4
14
5.1
0.6
5.7
0.6
6.8
0.8
7.4
0.9
7.9
1.0
9.1
1.1
10.2
1.4
16
5.1
0.6
5.7
0.6
6.8
0.8
7.4
0.9
7.9
1.0
9.1
1.1
10.2
1.5
18
5.1
0.6
5.7
0.7
6.8
0.8
7.4
0.9
7.9
1.0
9.1
1.2
10.2
1.5
20
5.1
0.7
5.7
0.8
6.8
0.9
7.4
1.0
7.9
1.1
9.1
1.3
10.2
1.7
21
5.1
0.8
5.7
0.8
6.8
1.0
7.4
1.1
7.9
1.2
9.1
1.4
10.2
1.7
23
5.1
0.8
5.7
0.9
6.8
1.1
7.4
1.2
7.9
1.3
9.1
1.5
10.2
1.9
25
5.1
0.9
5.7
1.0
6.8
1.2
7.4
1.3
7.9
1.4
9.1
1.7
10.2
2.1
27
5.1
1.0
5.7
1.1
6.8
1.3
7.4
1.4
7.9
1.5
9.1
1.8
10.2
2.3
29
5.1
1.1
5.7
1.2
6.8
1.4
7.4
1.5
7.9
1.7
9.1
2.0
10.2
2.4
31
5.1
1.2
5.7
1.3
6.8
1.5
7.4
1.7
7.9
1.8
9.1
2.1
10.2
2.6
33
5.1
1.3
5.7
1.4
6.8
1.6
7.4
1.8
7.9
2.0
9.1
2.3
10.2
2.8
35
5.1
1.4
5.7
1.5
6.8
1.8
7.4
1.9
7.9
2.1
9.1
2.5
10.2
3.0
37
5.1
1.5
5.7
1.6
6.8
1.9
7.4
2.1
7.9
2.3
9.1
2.7
10.2
3.3
39
5.1
1.6
5.7
1.7
6.8
2.1
7.4
2.2
7.9
2.5
9.1
2.9
10.2
3.5
41
5.1
1.7
5.7
1.8
6.8
2.2
7.4
2.4
7.9
2.7
9.1
3.1
10.2
3.8
43
5.1
1.8
5.7
2.0
6.8
2.4
7.4
2.6
7.9
2.9
9.1
3.4
10.2
4.1
45
5.1
1.9
5.7
2.1
6.8
2.6
7.4
2.8
7.9
3.1
9.1
3.6
10.2
4.4
48
5.1
2.2
5.7
2.4
6.8
2.9
7.4
3.2
7.9
3.5
9.1
4.1
9.6
4.4
50
5.1
2.3
5.7
2.6
6.8
3.1
7.4
3.4
7.9
3.8
8.4
3.9
8.7
3.9
52
5.1
2.5
5.7
2.8
6.4
3.1
6.7
3.2
7.0
3.3
7.1
3.1
7.3
3.1
Abbreviations:
CR: Combination ratio
TC: Total capacity (kW)
PI: Power input (compressor + outdoor fan motor) (kW)
Notes:
Shaded cells indicate rating condition.
Table continued on next page …
