Page 18
SASH
1-1/2"min
(38 mm)
Board thickness
as required, for
proper pitch to
rear, along entire
sill. Fasten with
nails or screws.
Storm window
frame or other
obstruction.
Fig. 15
7. INSTALL WEATHER STRIPPING (only
be applicable to Energy star models)
In order to minimize air leaks between
the room air conditoner and the window
opening, trim the weather sttipping with
a proper length, peel off the protective
backing and plug any gaps if needed
(Fig. 14).
If AC is Blocked by Storm Window
Add wood as shown in Fig. 15, or remove
storm window before air conditioner is
installed.
If storm window frame must remain,
be sure the drain holes or slots are not
caulked or painted shut. Accumulated
rain water or condensation must be
allowed to drain out.
Fig. 14
Removing AC From Window
• Turn AC off, and disconnect power cord.
• Remove sash seal from between
windows, and unscrew safety lock.
• Remove screws installed through frame
and frame lock.
• Close (slide) side panels into frame.
• Keeping a firm grip on air conditioner,
raise sash and carefully remove
• Be carefully not to spill any remaining
water while lifting unit form window.
Store parts WITH air conditioner.
Installation
Instructions
