13
Step 3
Install the housing into the wall and secure. Ensure the
foam seals are not damaged. Flash, seal or fill gaps
around the inside and outside to provide satisfactory
appearance and protection against the weather, insects
and rodents.
Installation of the unit into the Housing
1. Slide the unit into the housing until it is firmly
against the rear of the housing. Care is required to
ensure the foam sealing strips on the housing remain in
position.
2. Connect the air conditioner to the power and
position excess cord length beneath the air conditioner
base.
3. Engage the chassis fixing brackets into the bottom
housing rail and secure to the base with the screw
provided.
4. Remove the front panel from it's carton and plastic
bag and fit as per the Installation instruction.
5. Switch unit on. Check for operation of the unit and
check for vibration in the installation.
6. Fit the drain pan to the housing and run a drain line
to a suitable location if required.
Installations of the unit into the wall
