Midea MWSC340A-FB3 - Outline Dimension

Flooded type water cooled screw chiller (PCB Control)
15
4. Outline dimension
Single head (MWSC340~890A-FB3)
Unit: mm
Model
Ａ
Ｂ
Ｃ
Ｄ
Ｅ
Ｆ
Ｇ
Ｈ
J
K
L
Water
inlet/outlet Dim.
MWSC340A-FB3
3550
1220
1730
2850
1100
411
260
250
850
260
541
DN150
MWSC440A-FB3
3550
1220
1800
2850
1100
411
260
250
850
260
541
DN150
MWSC540A-FB3
3550
1220
1900
2850
1100
411
260
250
850
260
541
DN150
MWSC690A-FB3
3600
1420
2000
2850
1300
451
280
300
1000
280
591
DN200
MWSC805A-FB3
3600
1440
2020
2850
1300
451
280
300
1000
280
591
DN200
MWSC890A-FB3
3600
1440
2020
2850
1300
451
280
300
1000
280
591
DN200
Dual heads(MWSC1080~1780A-FB3)
Unit: mm
Model
Ａ
Ｂ
Ｃ
Ｄ
Ｅ
Ｆ
Ｇ
Ｈ
J
K
L
Water inlet/outlet Dim.
MWSC1080A-FB3
4600
1520
2035
3850
1400
443
350
325
1075
350
618
DN200
MWSC1200A-FB3
4600
1520
2035
3850
1400
443
350
325
1075
350
618
DN200
MWSC1385A-FB3
4600
1520
2035
3850
1400
443
350
325
1075
350
618
DN200
MWSC1620A-FB3
4800
1620
2250
3850
1500
468
350
350
1150
350
643
DN200
MWSC1780A-FB3
4800
1620
2250
3850
1500
468
350
350
1150
350
643
DN200
NOTE: Drawings are not contractually binding. Before designing an installation, consult the certified dimensional drawings
supplied with the unit or available on request.
For the positioning of the fixing points, weight distribution and center of gravity coordinates please refer to the dimensional
drawings.
Cooling
water inlet
Chilled
water inlet
Cooling
water outlet
Chilled
water outlet
B
E
J
K
H
F
L
C
G
Cooling
water inlet
Chilled
water inlet
Cooling
water outlet
Chilled
water outlet
B
E
J
K
H
F
L
C
G
A
D
D
A
D
